The Cisco Meraki MS120-24P-HW delivers enterprise-grade switching with seamless Meraki cloud-based management. With 24 PoE+ Gigabit ports and 4 SFP uplinks, it enables flexible deployments in offices, schools, and retail branches requiring high performance, intelligent security, and centralized monitoring.
This model offers a powerful 370W PoE+ budget for powering access points, VoIP phones, and surveillance cameras, while offering intuitive provisioning, VLAN control, and remote troubleshooting via Meraki Dashboard.
Key Features & Benefits
24 x 10/100/1000 Mbps RJ45 Ethernet ports with PoE+ support
4 x 1GbE SFP uplink ports for fiber expansion or redundancy
Switching capacity of 56 Gbps with forwarding rate of 41.67 Mpps
370W total PoE+ power budget with advanced Layer 2 and L3 features
Managed via Meraki Cloud Dashboard with zero-touch provisioning
Fanless design for quiet operation in office environments
Enterprise security: 802.1X, RADIUS, DHCP snooping, MAC whitelisting
Ideal Uses
Office deployments requiring PoE for phones, wireless APs, and CCTV
Branch networks that need centralized remote management
Schools and campuses needing VLAN and multicast traffic support
Retail stores needing reliable Layer 2+ switching with PoE simplicity
Specifications
Condition: Refurbished device with minor scratches and scuffs. Device has been extensively tested and is fully functional.
Brand: Cisco Meraki
Model: MS120-24P-HW
Switch Type: Managed Gigabit PoE+ Switch
Ports: 24 x 10/100/1000BASE-T RJ45 with auto-MDIX
Uplink Ports: 4 x 1GbE SFP
PoE+ Budget: 370W total (across 24 ports)
Switching Capacity: 56 Gbps
Forwarding Rate: 41.67 Mpps
MAC Address Table: 16K entries
Layer 2/3 Features: VLANs, RSTP/STP, IGMP Snooping, DHCP Relay
Security Features: 802.1X, RADIUS, ACLs, Port Security, STP Guard
Management: Cloud-based via Meraki Dashboard
Remote Diagnostics: Cable test, alerts, live packet capture
Operating Temperature: 0°C to 45°C
Humidity: 5% to 95% non-condensing
Mounting: 1U Rack-mountable (rack kit included)
Fanless: Yes
Power Input: 100240VAC, 4763Hz
Power Consumption: Idle: 28W / Full Load: 425W
Dimensions: 44 x 25 x 4.4 cm
Weight: 4.20 kg
Warranty: 3 Month Carry-in Warranty
What's in the Box: Switch
