THIS MACHINE COMES WITHOUT SOFTWARE , BUT MACH 3 CAN EASILY BE DOWNLOADED FROM THE INTERNET
Effective working travel: | 250(X)mm*180(Y)mm*30(Z)mm |
Max.thickness of the meterials : | ≤30mm(the distance between Z axis and the bottom of the working station) |
Work table dimension: | 270mm*370mm |
Frame materials: | aluminum |
Working speed: | 0 ~ 800mm/min |
Max. speed: | 1000mm/min |
Resetting accuracyï¼Â | 0.05mm |
Engraving accuracy: | better than 0.04mm (has been tested) |
Spindle precision: | 0.01mm |
Driver typeï¼Â | stepper motor |
Lead screw : | trapezoid screw |
Blade diameter : | 1-6mm |
Command Language: | G code |
Power comsumption: | 300W |
Operating system: | WIN2000/XP |
Running circumstance temperature: | -10â ~50 â |
Relative humidity: | 20% - 90% |
Power source: | AC 220/50Hz or AC110/60Hz |
Rotation Speed of Spindle Motor : | 500-20000r/min |
Gross weight: | 30KG |
Net weight : | 25kg |
