1Corsair TX850 , Eps12V , ATX 12V V2.2 - 850w ( 12v : 840w ) , nvidia SLi ready , 80PLUS bronze certified for energy saving , 24pin ( 4pin detachable ) , with active-PFC , 4 x 8pin (26) PCI-E power connectors , 8x SATA , 1x 140mm thermal controled fan with OCP, OVP, SCP, UVP - 5 years warranty - no power cord
Features: * Conforms to the latest ATX12V v2.31 and EPS 2.92 standards, and is backward compatible with the ATX12V 2.2 and ATX12V 2.01 standards * A dedicated single +12V rail offers simple configuration and maximum compatibility with the latest graphics cards and other components * An ultra-quiet, 140mm double ball-bearing fan delivers excellent airflow with exceptionally low noise levels by varying fan speed in response to temperature * Complies with the European Union ErP Directive (2009/125/EC) so the power consumption of the whole system, in either standby or off mode, can be less than 1W when used with a properly configured, ErP-compliant motherboard * 80 PLUS Bronze certified, delivering up to 85% energy efficiency under real-world load conditions * Active Power Factor Correction (PFC) with PF value of 0.99 * Universal AC input from 90~264V * Over-voltage, under-voltage, over-current, and short circuit protection provide maximum safety for your critical system components * High-quality Japanese capacitors provide uncompromising performance and reliability * A five year warranty and lifetime access to Corsair's legendary technical support and customer service * Safety Approvals: cTUVus, CE, CB, FCC Class B, TV, CCC, C-tick
Specs: Dimensions: 150mm(W) x 86mm(H) x 160mm(L) Power: 850 Watts 80 Plus Bronze certified ATX Connector: 1 EPS Connector: 1 PCI-E Connectors: 4 4 Pin Peripheral Connectors: 8 SATA Connectors: 8 Floppy Connectors: 2 MTBF: 100,000 hours
| CMPSU-850TXV2 |
| Voltage | +3.3V | +5V | +12V | -12V | +5Vsb |
| Max. Current | 30A | 30A | 70A | 0.8A | 3A |
| Max Combined Wattage | 150W | 840W | 9.6W | 15W |
| 850 @ 50°C ambient temperature |
