CSB 9 A-H 12 Volt Sealed AGM Battery - CSB Battery 2.80kg

9 were available / new

Indicative market price: R399.95

R349.95

13% off

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 3 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

World Of Fishing216

100.00 % Positive ratings

Buyer protection

How you're covered

Get it now, pay later

Condition

New

Location

South Africa

Product code

7157-HR1234WF2

Bob Shop ID

300056583

CSBHR1234WF2

9 A-H Valve Regulated Sealed Lead Acid Battery

Featuring Absorbed Glass Mat (AGM) Plate Separation

Perfect for Powering FishFinders on Pontoons and Kayaks

Name: CSB 9 A-H 12 Volt Sealed AGM Battery - CSB Battery 2.80kg
SKU: 7157-HR1234WF2
Price: 349.95 ZAR
Availability: SoldOut

Specification

Cells Per Unit

Voltage Per Unit

12 V

Capacity

34W @ 15 minute-rate to 1.67V per cell @ 25°C (77°F)

Weight

Approx. 2.50kg. (5.51lbs.)

Maximum Discharge current

100/130A (5sec.)

Internal Resistance Approx.

Approx. 19mΩ

Operating Temperature Range

Discharge：-15℃~50℃(5°F~122°F)
Charge：-15℃~40℃(5°F~104°F)
Storage：-15℃~40℃(5°F~104°F)

Nominal Operating Temperature Range

25°C ± 3°C (77°F ± 5°F)

Float charging voltage

13.5 to 13.8 VDC/unit Average at 25°C (77°F)

Recommended Maximum Charging current limit

3.4A

Equalization and Cycle Service

14.4 to 15.0 VDC/unit Average at 25°C (77°F)

Self Discharge

It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃

Terminal

F2-Faston Tab250

Container Material

ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request.

Constant Current Discharge Characteristics Unit:Amperes (25°C,77°F)

F.V/Time	2MIN	4MIN	6MIN	8MIN	10MIN	15MIN	20MIN	30MIN	60MIN	90MIN
1.60V	73.80	49.20	36.80	29.70	25.40	18.50	14.60	10.50	5.99	4.25
1.67V	65.80	44.80	34.40	28.20	24.20	17.80	14.10	10.30	5.86	4.15
1.70V	62.20	42.90	33.30	27.50	23.60	17.40	13.80	10.10	5.80	4.11
1.75V	56.30	39.80	31.60	26.20	22.70	16.80	13.50	9.90	5.69	4.05
1.80V	50.30	36.40	29.70	24.90	21.70	16.20	13.10	9.66	5.60	3.99
1.85V	43.30	32.90	27.60	23.50	20.70	15.60	12.70	9.39	5.50	3.92

Constant Power Discharge Characteristics Unit:Watts (25°C,77°F)

F.V/Time	2MIN	4MIN	6MIN	8MIN	10MIN	15MIN	20MIN	30MIN	60MIN	90MIN
1.60V	706.00	506.00	395.00	328.00	286.00	211.00	169.00	124.00	71.70	50.80
1.67V	645.00	470.00	376.00	315.00	276.00	205.00	165.00	121.00	70.50	50.10
1.70V	618.00	454.00
