| Specification |
| DEVICE INTERFACES | RJ-11 ADSL port |
| | 4 RJ-45 10/100BASE-TX Ethernet ports with auto MDI/MDIX |
| | Built-in 802.11n Wireless Lan |
| | Factory reset button |
| | WPS button |
| | Wireless on/off switch (optional) |
| | Power on/off switch |
| | USB host 2.0 |
| WIRELES LAN | 802.11b/g/n standards |
| | Wireless speed: up to 54 Mbps (802.11g), 300 Mbps (802.11n)1 |
| | Frequency range: 2.4 GHz to 2.484 GHz |
| | Antennas: Dual 2x2 built-in MIMO antennas |
| | 64/128 bits WEP data encryption |
| | WPA/WPA2 (Wi-Fi Protected Access) security |
| | MAC address-based access control |
| ADSL STANDARDS | ADSL standards: Multi-mode, ANSI T1.413 Issue 2, ITU G.992.1 (G.dmt) Annex A, ITU G.992.2 (G.lite) Annex A, ITU G.994.1 (G.hs) |
| | ADSL2 standards: ITU G.992.3 (G.dmt.bis) Annex A/L/M, ITU G.992.4 (G.lite.bis) Annex A |
| | ADSL2+ standards: ITU G.992.5 Annex A/ |
| | ADSL2+ standards: ITU.G.992.5 Annex L/M (optional) |
| ADSL DATA RATES | G.dmt: 8 Mbps downstream, 832 Kbps upstream |
| | G.lite: 1.5 Mbps downstream, 512 Kbps upstream |
| | ADSL2: 12 Mbps downstream, 1 Mbps upstream |
| | ADSL2+: 24 Mbps downstream, 1 Mbps upstream |
| ATM & PPP PROTOCOLS | ATM Forum UNI3.1/4.0 PVC (up to 8 PVCs) |
| | ATM Adaptation Layer Type 5 (AAL5) |
| | ATM QoS (Traffic Shaping) |
| | Bridged or routed Ethernet encapsulation |
| | VC and LLC based multiplexing |
| | PPP over Ethernet (PPPoE) |
| | PPP over ATM (RFC 2364) |
| | ITU-T I.610 OAM F4/F5 |
| | |
| ROUTER FEATURES | NAT & NAPT |
| | DHCP server/client/relay |
| | Static Routing, RIP v.1, v.2 |
| | Universal Plug and Play (UPnP) Compliant |
| | Dynamic Domain Name System (DDNS) |
| | Virtual Server |
| | SNTP, DNS proxy, and IGMP proxy |
| | Supports IPv6 |
| FIREWALL | Built-in NAT firewall |
| | Stateful Packet Inspection (SPI) |
| | DoS attacks prevention |
| | Packet filtering (IP/ICMP/TCP/UDP) |
| VIRTUAL PRIVATE NETWORK (VPN) | Multiple PPTP/IPSec/L2TP pass-through |
| DEVICE CONFIGURATION/MANAGEMENT | Installation Wizard (optional) |
| | Web-based GUI for configuration, firmware upgrade |
| | Code lock to prevent improper firmware upgrade |
| | Telnet |
| | Syslog monitoring |
| | TR-069 Client (optional) |
| | WPS |
| USB | USB printing |
| | USB storage |
| | Compatible 3G USB adapter connection |
| QUALITY OF SERVICE | 802.1p (0 to 7) traffic tagging |
| | IGMP Snooping with 32 Multicast groups |
| | PVC/VLAN port mapping (bridge mode) |
| SECURITY | IGMP |
| | PVC/VLAN port mapping (bridge mode) |
| | Parental Control (URL blocking, scheduling) |
| POWER INPUT | Through 1A external power adapter |
| DIAGNOSTIC LEDs | Power |
| | LAN (1 to 4) |
| | WLAN |
| | DSL |
| | Internet |
| | WPS |
| | USB |
| DIMENSIONS (L X W X H) | 162 x 116.8 x 33 mm |
| | (6.4 x 4.6 x 1.3 inches) |
| OPERATING TEMPERATURE | 0 to 40 °C (32 to 104 °F) |
| STORAGE TEMPERATURE | (-)20 to 70 °C (-4 to 158 °F) |
| OPERATING HUMIDITY | 5% to 95% non-condensing |
| CERTIFICATIONS | CE |
| | FCC |
