D-Link DWL-2100AP Wireless Access Point

D-Link DWL-2100AP Wireless Lan 802.11g 108Mbps, Access Point, Bridge, 64/128/152 Bit Wep Encryption, 10/100 Base-TX

The D-Link DWL-2100AP Access Point has been verified and successfully passed through the Intel Wireless Verification Program, which tests the compatibility of various access point devices and wireless service providers with common configuration of notebooks built on Intel® Centrino™ mobile technology**.

The DWL-2100AP features WDS (Wireless Distribution System) that can be configured to perform in any one of five modes: a Wireless Access Point, a Point-to-Point (PtP) bridge with another DWL-2100AP, a Point-to-Multipoint (PtMP) bridge, a Repeater for range extension, or as a Wireless Client. The WDS feature makes the DWL-2100AP an ideal solution for quickly creating and extending a wireless local area network (WLAN) in offices or other workplaces, or even at hotspots.

The DWL-2100AP Wireless Access Point comes with a detachable antenna utilizing a reverse SMA connector. By simply attaching a D-Link wireless antenna, you can increase the wireless range of the DWL-2100AP.

Device Management
Web-Based – Internet Explorer v6 or later

Data Rate
For 802.11g:
108, 54, 48, 36, 24, 18, 12, 9 and 6Mbps

For 802.11b:
11, 5.5, 2, and 1Mbps

Security
64-, 128-, 152-bit WEP
WPA & WPA 2 – Wi-Fi Protected Access (WPA & WPA2-TKIP/PSK/AES)
MAC Address Access Control List

Wireless Frequency Range
2.4GHz to 2.4835GHz

Wireless Operating Range*
802.11g (Full Power with 2dBi gain diversity dipole antenna)
Range will vary subject to environmental condition

Antenna Type
Dipole antenna with 2dBi gain
