The DIR-825 AC1200 Wi-Fi Gigabit Router is a powerful wireless networking solution designed for Small Office/Home Office (SOHO) environments. By combining high-speed 802.11ac Wi-Fi with dual-band technology and Gigabit Ethernet ports, the DIR-825 provides a seamless networking experience with a high degree of convenience and flexibility for SOHOs. The DIR-825’s SOHO-class advanced security features keep data safe from unwanted network intruders. This together with the increased range and reliability of Wireless AC technology, helps provide a safe and secure network for devices further into your home or office.
High-Speed Wired and Wireless Connectivity
The DIR-825 AC1200 Wi-Fi Gigabit Router upgrades your network to the latest high-speed wireless technology to bring you lightning-fast Wi-Fi speeds of up to 1200 Mbps so you can meet the ever-greater demand from multimedia applications. Enjoy seamless high definition streaming media, Internet phone calls, online gaming, and content-rich web surfing throughout your home or office. In addition, 10/100/1000 Gigabit Ethernet ports give you solid, dependable wired performance for devices such as Network-Attached Storage (NAS), media centres, and gaming consoles. The built-in Quality of Service (QoS) engine allows you to prioritize important traffic to ensure that your favourite applications are receiving optimal bandwidth.
Dual-Band Wireless for Seamless Performance
The DIR-825 AC1200 Wi-Fi Gigabit Router features dual-band wireless, allowing you to operate two concurrent, high-speed Wi-Fi bands for ultimate wireless performance. Surf the web or make important Internet phone calls on the 2.4 GHz band, while simultaneously streaming digital media on the 5 GHz band. What’s more, each band can operate as a separate Wi-Fi network, giving you the ability to customize your network according to your connectivity needs. You can even configure a guest zone to give visitors Internet access without compromising the security of your SOHO network.
Easy to Set Up and Secure
Sharing your Internet connection doesn’t have to be a complicated process - just open a web browser to access the setup wizard and follow the easy step-by-step instructions to get started. Configure, apply, and set up WPA/ WPA2 wireless security in minutes with the wireless network setup wizard, or use Wi-Fi Protected Setup (WPS), which establishes a secure connection to new devices without the need to enter settings or create passwords. In addition, the built-in firewall requires no setup, protecting you against malicious attacks from the Internet, and access control features allow you to restrict access to your network giving you greater control over network users.
- 1X 10/100/1000 Gigabit Ethernet WAN port for fastpaced Internet access
- 4X 10/100/1000 Gigabit Ethernet LAN ports give you high-speed wired connectivity
- USB 2.0 for local network sharing
- Concurrent dual-band wireless for connections up to 1200 Mbps
- QoS engine to prioritize important traffic and deliver uninterrupted bandwidth
Specifications
Device Interfaces
• IEEE 802.11 ac/n/g/b/a wireless LAN
• 10/100/1000 Gigabit Ethernet WAN port
• Four 10/100/1000 Gigabit Ethernet LAN ports
• USB 2.0 port
LEDs
• Power
• Internet
• WLAN (2.4 GHz & 5 GHz)
• LAN (x4)
• WPS
• USB
Antenna Type
• Four external antennas
Data Signal Rate
• 2.4 GHz
• Up to 300 Mbps1
• 5 GHz
• Up to 867 Mbps1
Standards
• IEEE 802.11ac
• IEEE 802.11n
• IEEE 802.11g
• IEEE 802.3ab
• IEEE 802.11b
• IEEE 802.11a
• IEEE 802.3u
Minimum Requirements
• Windows 10/8.1/8/7/Vista/XP SP3 or MAC OS X 10.6 or higher
• Internet Explorer 9, Firefox 20.0, Chrome 25.0, Safari 5.1,or other Java-enabled browser
• Network interface card
• Cable/DSL modem or other Internet Service Provider equipment with Ethernet port
Security
• WPA & WPA2 (Wi-Fi Protected Access)
• WPS (Wi-Fi Protected Setup)
Advanced Features
• Web setup wizard
• QoS (Quality of Service)
• DMZ (Demilitarized Zone)
• Firewall - Network Address Translation (NAT)
• Guest zone
• IPv6 ready
Dimensions
• 202 x 132.2 x 28 mm (7.95 x 5.20 x 1.10 inches)
Weight
• 360 g (12.7 ounces)
Power Adaptor
• Input: 100 to 240V AC, 50/60 Hz
• Output: 12 V, 1.5 A
Temperature
• Operating: 0 to 40 `b0C (32 to 104 `b0F)
• Storage: -20 to 65 `b0C (-4 to 149 `b0F)
Humidity
• Operating: 10% to 90% non-condensing
• Storage: 5% to 95% non-condensing
Certifications
• FCC
• CE 2
• RoHS
• LVD
