> Orange port supports 60W Hi-PoE standard
> Intelligent PoE
> Plug-and-play
> Ethernet port supports eight-pin PoE
> Wide range of working temperature: 10 to +55°C (14°F to +131°F)
> Full gigabit port design
Performance | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Layer | Layer 2 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Switching Capacity | 32 Gbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Forwarding Rate | 23.808 Mpps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packet Buffer Memory | 4.1 Mb | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
MAC Table Size | 8K | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Hardware Feature | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Standard Power Supply | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE | Yes | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet Port | 16 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet Port Rate | 1 Gbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Number of Bussiness Card Slots | Port 1port 16: 16 × RJ-45 10M/100M/1000M (PoE) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | 100V AC 240V AC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | 10°C to +55°C (14°F to +131°F) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | 10%90% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Storage Humidity | 5%95% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | Idling: 18W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Standard | IEEE802.3af, IEEE802.3at, Hi-PoE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Budget | Port 1port 2 60W, port 3port 16 30W, total 190W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
PoE Pin Assignment | PoE/Hi-PoE: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
ESD | Air discharge: 8kV | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Thunderproof | Common mode: 4kV | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Product Dimensions | 285 mm × 104.6 mm × 28 mm (11.22" × 4.12" × 1.10") | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Packaging Dimensions | 455 mm × 270 mm × 92 mm (17.91" × 10.63" × 3.62") |
