Camera |
Image Sensor | 1/2.8" CMOS |
Pixel | 2 MP |
Max. Resolution | 1920 (H) × 1080 (V) |
ROM | 4 GB |
RAM | 1 GB |
Electronic Shutter Speed | 1/1 s1/30,000 s |
Scanning System | Progressive |
Min. Illumination | Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux (IR light on) |
Illumination Distance | 150 m (492.13 ft) (IR) |
Illuminator On/Off Control | Zoom Prio; Manual; Smart IR |
Illuminator Number | 4 (IR) |
Lens |
Focal Length | 4.8 mm120 mm |
Max. Aperture | F1.6F3.5 |
Field of View | H: 58.5°2.8°; V: 33.2°1.5°; D: 67.5°3.2° |
Optical Zoom | 25× |
Focus Control | Auto; semi-auto; manual |
Close Focus Distance | 0.1 m1.5 m (0.33 ft4.92 ft) |
Iris Control | Auto; manual |
DORI Distance | Detect | Observe | Recognize | Identify |
1,614 m (5,292 ft) | 646 m (2,119 ft) | 323 m (1,060 ft) | 161 m (528 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
PTZ |
Pan/Tilt Range | Pan: 0° to 360° endless
Tilt: 15° to +90°, auto flip 180° |
Manual Control Speed | Pan: 0.1°/s300°/s Tilt: 0.1°/s200°/s |
Preset Speed | Pan: 400°/s; Tilt: 300°/s |
Preset | 300 |
Tour | 8 (up to 32 presets per tour) |
Pattern | 5 |
Scan | 5 |
Power-off Memory | Yes |
Idle Motion | Preset; Pattern; Tour; Scan |
Intelligence |
Video Metadata | Detects motor and non-motor vehicles, faces and human bodies. It also performs tracking, takes snapshots, uploads high-quality face images and optimizes images. It extracts attributes from motor vehicles, detecting up to 10 attributes for them. |
IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification |
Face Detection | Supports face detection, face bounding box, capturing snapshots, uploading face snapshots, enhancing face images, and selecting a preferred image among a group of snapshots. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. The attributes are gender, age, glasses, mask, mustache and expressions. The expressions are angry, sad, hate, scared, surprised, calm, happy and confused. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots. |
People Counting | Supports tripwire for people counting at entrances and exits, counting the number of people staying in an area and queuing in an area, and displaying and exporting reports based on the day, week and month. |
Auto Tracking | Yes |
SMD | SMD 4.0 |
Acupick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. |
Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. |
Video |
|
