Camera |
Image Sensor | 1/2.8" CMOS |
Pixel | 2 MP |
Max. Resolution | 1920 (H) × 1080 (V) |
ROM | 4 GB |
RAM | 1 GB |
Electronic Shutter Speed | 1/1 s1/30,000 s |
Scanning System | Progressive |
Min. Illumination | Color: 0.005 Lux@F1.6
B/W: 0.0005 Lux@F1.6
0Lux (IR light on) |
Illumination Distance | 150 m (492.13 ft) |
Illuminator On/Off Control | Zoom Prio; Manual; Smart IR; Off |
Illuminator Number | 4 (IR) |
Lens |
Focal Length | 3.95 mm177.75 mm |
Max. Aperture | F1.6F4.95 |
Field of View | H:65.7°1.9°V:39.4°1.1°D:73.1°2.1° |
Optical Zoom | 45× |
Focus Control | Auto; semi-auto; manual |
Close Focus Distance | 0.1 m1 m (0.33 ft3.28 ft) |
Iris Control | Auto; manual |
DORI Distance | Detect | Observe | Recognize | Identify |
2451.7 m (8043.64 ft) | 972.9 m (3191.93 ft) | 490.3 m (1608.60 ft) | 245.2 m (804.46 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
PTZ |
Pan/Tilt Range | Pan: 0° to 360° endless
Tilt: 15° to +90°, auto flip 180° |
Manual Control Speed | Pan: 0.1°/s300°/s; Tilt: 0.1°/s200°/s |
Preset Speed | Pan: 400°/s; Tilt: 300°/s |
Preset | 300 |
Tour | 8 (up to 32 presets per tour) |
Pattern | 5 |
Scan | 5 |
Power-off Memory | Yes |
Idle Motion | Pattern;Preset;Scan;Tour |
Intelligence |
IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
Face Detection | Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first. |
Video Metadata | Detects motor and non-motor vehicles, faces and human bodies. It also performs tracking, takes snapshots, uploads high-quality face images and optimizes images. It extracts attributes from motor vehicles, detecting up to 10 attributes for them. |
People Counting | Uses advanced image processing technology to extract depth information from images. The extracted information is then processed by advanced, deep learning algorithms to analyze and detect human bodies, and track targets in real time. The camera provides statistics for separate individuals' entrance and exit with up to 95% counting accuracy. |
Auto Tracking | Yes |
SMD | SMD 4.0 |
Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. |
Acupick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. |
Video |
