System |
Main Processor | 64-bit high-performance Intel processor |
Controller | Single controller |
Memory | 4GB by default |
Operating System | Embedded LINUX |
User Interface | Web |
Working Mode |
Video Stream Mode | 320-channel (640Mbps) incoming and recording , 160-channel (320Mbps)forwarding, 32-channel (64Mbps) playback |
IP SAN Mode | Storage bandwidth 2.7Gbps
Write-through: 320Mbps;Write-back: 480Mbps
|
Storage |
HDD Amount | 36 HDDs, Up to 10 TB capacity for each HDD SATA HDD composite connection |
miniSAS | 1 miniSAS ports, for storage extension |
HDD Installation | Additional HDD bracket, HDD hot-swap, HDD online replacement |
HDD Mode | Single, RAID 0/1/5/6/10/50/60(Enterprise-level HDDs are recommended), JBOD, hotspare
|
Storage Management |
HDD Manager | Non-working HDD hibernation to guarantee sound ventilation, reduce power consumption and enhance HDD life span HDD bad track mapping to enhance HDD life span
|
RAID Rebuild | Dynamically adjust RAID rebuild speed to guarantee system load balance |
Logic Volume Manager | Support iSCSI volume management, NAS(SMB/NFS/FTP) volume management |
Snapshot | Support snapshot function, create user volume to back data. |
Extract Frame | Support extracting P frame function. Customizied extracting period and frame rate setup. |
Cluster Service | N+M cluster service |
ANR | After diconnection, system can download the record file from the SD card on the network camera to maintain the full record file. |
Shortcut RAID Creation | Click one button to create RAID conveniectly. |
Playback and Backup |
Search Mode | Time/Date, Channel, Alarm, MD and Exact Search (accurate to second) |
Playback Function | Play, Pause, Stop, Fast play, Slow play, Full screen, Backup selection, Digital zoom |
Backup Mode | USB Device/Network/eSATA Device |
Third-party Support |
Third-party Support | Dahua, AEBell, Arecont, AXIS, Dynacolor, HIKVISION, LG, Panasonic, PSIA, Samsung, Sony, Vivotec, and more
|
