Category | Specifications |
---|---|
Camera | |
Image Sensor | 1 / 2.7 CMOS |
Max. Resolution | 2304 (H) × 1296 (V) |
Electronic Shutter Speed | Auto / Manual 1 / 3 s 1 / 100,000 s |
Illumination Distance | Up to 30 m (98.43 ft) (IR); Up to 30 m (98.43 ft) (Warm Light) |
Illuminator On / Off Control | Auto |
Illuminator Number | 2 (IR LED); 2 (Warm Light) |
Angle Adjustment | Pan: 0° 355°; Tilt: 0° 90° |
Lens | |
Max. Aperture | F1.6 |
Field of View | H: 87°; V: 44°; D: 105° |
Intelligence | |
Vehicle Detection | Yes |
Human Detection | Yes |
Video | |
Video Compression | H.265 |
Video Frame Rate | Main stream: 2304 × 1296 @ (1 25 / 30 fps) Sub stream: 640 × 360 @ (1 25 / 30 fps) |
Resolution | 3M (2304 × 1296); nHD (640 × 360) |
Video Bit Rate | H.265: 80 kbps 4096 kbps |
Day / Night | Auto (ICR) / Colour / B / W |
WDR | DWDR |
Motion Detection | Yes |
Smart Illumination | Yes |
Image Rotation | 0° / 180° |
Audio | |
Built-in Mic | Yes |
Built-in Speaker | Yes |
Audio Compression | G.711a |
Network | |
Network Port | RJ-45 (10 / 100 Base-T) |
Wi-Fi | IEEE 802.11b / g / n / ax 2.412 2.472 GHz, 2.4 G |
Storage | Micro SD card (up to 256 GB) |
Management Software | DMSS |
Mobile Client | iOS; Android |
Certification | |
Certifications | CE |
Power | |
Power Supply | 12 VDC |
Power Consumption | Basic: 1.56 W; Max.: 4.56 W (H.265 + Warm Light On) |
Environment | |
Operating Temperature | 20 °C to +50 °C (4 °F to +122 °F) |
Operating Humidity | 95% |
Structure | |
Casing Material | Plastic |
Product Dimensions | 116 mm × 138 mm × 139 mm (4.57 × 5.43 × 5.47) (L × W × H) |
Net Weight | 425 g (0.94 lb) |
