Camera |
Image Sensor | 1/2.8" CMOS |
Pixel | 4 MP |
Max. Resolution | 2560 (H) × 1440 (V) |
ROM | 4 GB |
RAM | 1 GB |
Electronic Shutter Speed | 1/1 s1/30,000 s |
Scanning System | Progressive |
Min. Illumination | Color: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux@F1.6 (IR light on) |
Illumination Distance | 100 m (328.08 ft) (IR) |
Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off |
Illuminator Number | 4 (IR) |
Lens |
Focal Length | 5 mm125 mm |
Max. Aperture | F1.6F3.6 |
Field of View | H: 51.9°3.0°; V: 39.7°2.2°; D: 63.1°3.7° |
Optical Zoom | 25× |
Focus Control | Auto; semi-auto; manual |
Close Focus Distance | 0.1 m0.5 m (0.33 ft1.64 ft) |
Iris Control | Auto |
DORI Distance | Detect | Observe | Recognize | Identify |
2500 m (8208.10 ft) | 987.5 m (3239.83 ft) | 500 m (1640.42 ft) | 250 m (820.21 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
PTZ |
Pan/Tilt Range | Pan: 0° to 360° endless
Tilt: 15° to +90°, auto flip 180° |
Manual Control Speed | Pan: 0.1°200°/s
Tilt: 0.1°120°/s |
Preset Speed | Pan: 240°/s
Tilt: 200°/s |
Preset | 300 |
Tour | 8 (up to 32 presets per tour) |
Pattern | 5 |
Scan | 5 |
Power-off Memory | Yes |
Idle Motion | Pattern; Preset; Scan; Tour |
Intelligence |
IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification |
Face Detection | Supports face detection, optimization, tracking, capturing pictures, uploading high-quality face snapshots, and face enhancement; Supports attributes extraction. 6 attributes and 8 expressions: Gender, age, glasses, expressions (angry, sad, hate, scary, surprise, calm, happy and confused), mask, mustache; Supports face cutout: Face, one-inch photo. Capturing strategies include real-time capturing, optimization, and quality first |
SMD | SMD4.0 |
Acupick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets. |
Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets. |
Video |
Video Compression | H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+ |
Streaming Capability | 3 streams |
Resolution | 4M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
Video Frame Rate | Main stream: 4M/3M/1080p/1.3M/720p @(125/30 fps)
Sub stream 1: D1/CIF@ (125/30 fps)
Sub stream 2: 1080p/1.3M/720p @(125/30 fps) |
Bit Rate Control | CBR/VBR |
Video Bit Rate | H264: 9614,848 Kbps
H265: 388,960 Kbps |
|
