Camera |
Image Sensor | 1/1.8" CMOS |
Pixel | 4 MP |
Max. Resolution | 2560 (H) × 1440 (V) |
ROM | 4 GB |
RAM | 1 GB |
Electronic Shutter Speed | 1/1 s1/30,000 s |
Scanning System | Progressive |
Min. Illumination | Color: 0.001 lux@F1.6
B/W: 0.0001 lux@F1.6
0 lux (IR light on) |
Illumination Distance | 500 m (1,640.41 ft) (IR) |
Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off |
Illuminator Number | 10 (IR) |
Wiper | Smart wiper |
Lens |
Focal Length | 5.6 mm223 mm |
Max. Aperture | F1.6F4.9 |
Field of View | H: 63.9°2.1°; V: 37.3°1.2°; D: 71.2°2.4° |
Optical Zoom | 40× |
Focus Control | Auto; semi-auto; manual |
Close Focus Distance | 1 m5 m (3.28 ft16.40 ft) |
Iris Control | Auto |
DORI Distance | Detect | Observe | Recognize | Identify |
3,034.5 m (9,955.71 ft) | 1,198.6 m (3,932.41 ft) | 606.9 m (1,991.14 ft) | 303.4 m (995.41 ft) |
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
PTZ |
Pan/Tilt Range | Pan: 0° to 360° endless
Tilt: 30° to +90°, auto flip 180° |
Manual Control Speed | Pan: 0°/s180°/s
Tilt: 0°/s100°/s |
Preset Speed | Pan: 0°/s180°/s
Tilt: 0°/s100°/s |
Preset | 300 |
Tour | 8 (up to 32 presets per tour) |
Pattern | 5 |
Scan | 5 |
Power-off Memory | Yes |
Idle Motion | Preset; Pattern; Tour; Scan |
PTZ Protocol | DH-SD
Pelco-P/D (Auto recognition) |
Intelligence |
Video Metadata | Motor vehicle, non-motor vehicle, face, and human body detection; bounding box; optimization; capturing pictures; uploading high-quality face snapshots
Motor vehicle attributes: License plate, plate color, vehicle type, vehicle color, vehicle logo, vehicle model/year, sun visor, seatbelt, smoking, calling, ornament, and annual inspection sticker |
IVS (Perimeter Protection) | Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; vehicle/human alarm classification; linkage tracking |
Face Detection | Supports face detection, face bounding box, optimization, capturing snapshots, uploading high-quality face snapshots, and enhancing face images. Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots |
Auto Tracking | Yes |
SMD | Yes |
Video |
Video Compression | Smart H.265+; H.265; Smart H.264+; ... |
