> 4-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 4 MP (2688 × 1520) @20 fps, and supports 2560×1440 (2560 × 1440) @25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Built-in warm light, and the max. illumination distance is 30 m.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> Intelligent monitoring: Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
> Abnormality detection: Motion detection, video tampering, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
> Supports max. 256 G Micro SD card; built in Mic.
> 12 VDC/PoE power supply, easy for installation.
> IP67 protection.
> SMD Plus
Camera |
Image Sensor | 1/1.8" CMOS |
Max. Resolution | 2688 (H) × 1520 (V) |
ROM | 128 MB |
RAM | 256 MB |
Scanning System | Progressive |
Electronic Shutter Speed | Auto/Manual 1/3 s1/100,000 s |
Min. Illumination | 0.0005 lux@F1.0 |
S/N Ratio | >56 dB |
Illumination Distance | Up to 30 m (98.43 ft) (Warm light) |
Illuminator On/Off Control | Auto;Manual |
Illuminator Number | 2 (Warm light) |
Angle Adjustment | Pan: 0°360°
Tilt: 0°78°
Rotation: 0°360° |
Lens |
Lens Type | Fixed-focal |
Lens Mount | M16 |
Focal Length | 2.8 mm; 3.6 mm |
Max. Aperture | F1.0 |
Field of View | 2.8 mm: H: 112°; V: 60°; D: 134°
3.6 mm: H: 94°; V: 50°; D: 113° |
Iris Control | Fixed |
Close Focus Distance | 2.8 mm: 2 m (6.56 ft)
3.6 mm: 3 m (9.84 ft) |
DORI Distance | | Lens | Detect | Observe | Recognize | Identify | | 2.8 mm | 57.9 m
( 189.96 ft) | 23.2 m
( 76.12 ft) | 11.6 m
( 38.06 ft) | 5.8 m
( 19.03 ft) | | 3.6 mm | 70.3 m
( 230.64 ft) | 28.1 m
( 92.19 ft) | 14.1 m
( 46.26 ft) | 7.0 m
( 22.97 ft) | | *DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
Intelligence |
IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human); |
SMD | SMD Plus |
Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
Video |
Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
Smart Codec | Smart H.265+; Smart H.264+ |
Video Frame Rate | Main stream: 2688 × 1520@(120 fps)/2560 × 1440@(125/30 fps)
sub stream: 704 × 576@(125 fps)/704 × 480@(130 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
Streaming Capability | 2 streams |
Resolution | 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
Bit Rate Control | VBR;CBR |
Video Bit Rate | H.264: 32 kbps6144 kbps;
H.265: 12 kbps6144 kbps |
Day/Night | Color/B/W |
BLC |
