System |
Main Processor | Industrial-grade embedded processor |
Operating System | Embedded Linux |
Operation Interface | Web; local GUI |
AI |
AI by Camera | Face detection; face recognition; perimeter protection; SMD Plus |
AI by Device | Face detection; face recognition; perimeter protection; SMD Plus |
Perimeter Protection |
Perimeter Performance AI by Device(Number of Channels) | 1 |
Perimeter Performance of AI by Camera (Number of Channels) | 4 |
Face Detection |
Face Attributes | 6 attibutes: Gender; age group (6); glasses; expressions (8); mouth mask; beard |
Face Detection Performance of AI by Device (1080P) (Number of Channels) | 1 (up to 12 face images/second) |
Face Detection Performance of AI by Camera (Number of Channels) | 5 |
Face Recognition |
Face Database Capacity | Up to 10 face databases with 5,000 images |
Face Recognition Performance of AI by Device (1080P) (Number of Channels) | 1 (up to 4 face images/second) |
Face Recognition Performance of AI by Camera (Number of Channels) | 5 |
SMD Plus |
SMD Plus by Device | 4 |
SMD Plus by Camera | 6-channel SMD Plus (AI by camera): Detects tripwire and intrustion of human or vehicle; filters false alarms caused by leaves, raindrops and change of brightness away |
Video |
Access Channel | 8 channels |
Network Bandwidth | 80 Mbps for access, 80 Mbps for storage and 60 Mbps for forwarding. |
Resolution | 12MP; 8MP; 5MP; 4MP; 3MP; 2MP; 720p; D1 |
Decoding Capability | AI disabled: 1-channel 12MP@30 fps; 1-channel 8MP@30 fps; 2-channel 5MP@30 fps; 3-channel 4MP@30 fps; 6-channel 1080p@30 fps
AI enabled: 1-channel 8MP@30 fps; 1-channel 5MP@30 fps; 2-channel 4MP@30 fps; 4-channel 1080p@30 fps |
Video Output | 1 × VGA, 1 × HDMI (simultaneous) |
Multi-screen Display | 1, 4, 8, 9 views |
Third Party Camera Access | Onvif |
Compression |
Video | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
Audio | PCM; G711A; G711U; G726 |
Network |
Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; DDNS; Alarm Server; IP Search (Supports Dahua IP camera, DVR, NVS, etc.); P2P;Auto Registration |
Mobile Phone Access | Android; iOS |
Interoperability | ONVIF (profile T; profile S; profile G); CGI; SDK |
Browser | Chrome; IE9 or later; Firefox |
Record Playback |
Multi-channel Playback | Up to 8 channels |
Record Mode | Manual record; alarm recordings; motion detection recordings; scheduled recordings |
Storage | Local HDD and network |
Backup | USB device |
Playback Function | 1. Play; pause; stop; fast forward; fast backward; rewind; play by frame
2. Full screen; backup (vide clip/file); partially zom in; audio on/off |
Alarm |
General Alarm | Motion detection; privacy masking; video loss; PIR alarm; IPC alarm |
Anomaly Alarm | Camera offline; storage error; disk full; IP conflict; MAC conflict; login lock; cyber security excepti... |
