Input and Output |
Wireless Protection Zone | Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs) |
Port |
Buzzer | Hub: Built-in |
Button | Hub: 1 × reset, 1 × power, 1 × AP
Keyfob: 4 (Home, Away, Disarm, and SOS)
Door Detector: 1 × power button
PIR Detector: 1 × power button |
Indicator Light | Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)
Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)
Door Detector: 1 × green alarm indicator
PIR Detector: 1 × green alarm indicator |
Storage battery | Hub: Built-in lithium battery |
Network Mode | Hub: Ethernet, Wi-Fi and Cellular network (Supports installation of dual SIM cards. Only one card can be enabled at a time) |
Network Port | Hub: 1 × RJ-45 10 M/100 M Ethernet port |
Function |
Network Protocol | Hub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP |
Offline Cache | Hub: Max. 50 entries (ANR) |
Power Failure Protection for Configured Parameters | Hub: Yes |
Remote Update | All: Cloud update |
Video Linkage | Hub: Yes |
SMS | Hub: Yes (up to 5 phone numbers) |
Phone Call | Hub: Yes (up to 5 phone numbers) |
Low Battery Alarm | All: Yes |
Tamper Alarm | Hub: Yes
Door Detector: Yes
PIR Detector: Yes |
User Management | Hub: Share function for App users |
Search | Hub: Searching push messages, device status, and program version. Detecting signal strength.
Keyfob: Signal strength detection
Door Detector: Signal strength detection
PIR Detector: Signal strength detection |
Arm and Disarm | Hub: App; keyfob; schedule |
Wireless |
Carrier Frequency | All: 868.0 MHz868.6 MHz |
Transmitter Power (EIRP) | All: Limit 25 mW |
Communication Distance | Hub: Up to 2,000 m (6,561.68 ft) in an open space
Keyfob: Up to 900 m (2,952.76 ft) in an open space
Door Detector: Up to 1,200 m (3,937.01 ft) in an open space
PIR Detector: Up to 1,600 m (5,249.34 ft) in an open space |
Communication Mechanism | All: Two-way |
Encryption Mode | All: AES128 |
Frequency Hopping | All: Yes |
Wi-Fi |
Wi-Fi Standard | Hub:IEEE 802.11b/g/n |
Wi-Fi Frequency Range | Hub:2400-2483.5 MHz |
Wi-Fi Power Transmission | Hub:20 dBm@2400-2483.5 MHz |
Cellular Network |
Cellular Network Standard | Hub: GSM/WCDMA/LTE |
Frequency Range | Hub:
4G: FDD-LTE: B1/B3/B7/B8/B20; TDD-LTE: B38/B40/B41;
3G: WCDMA: B1/B5/B8;
2G: GSM: 1,800/900 MHz |
Transmitter Power (EIRP) | Hub:
4G: Power class3: 23 dBm±2 dB
3G: Power class3: 24 dBm+1/-3 dB
2G: Power class0: 30 dBm±3 dB (GSM900)
Power class5: 33 dBm±3 dB (GSM1800) |
Peripherals |
External Zone | Door Detector: 1-channel dry contact input |
Temperature |
Measuring Range (Temperature) | Door Detector: 15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
PIR Detector: 15 °C to +65 °C (+18.8 °F to +149 °F) (indoor) |
Measuring Precision (Temperature) | Door Detector: ± 1 °C (±... |
