Conductor |
Material | Oxygen free copper (99.97% purity) |
Diameter | 0.53 mm ± 0.01 mm (0.0207"±0.0004") |
Insulation |
Material | HDPE |
Min. Average Thickness | 0.21 mm (0.0083") |
Diameter | 0.95 mm±0.1 mm (0.0374"±0.004") |
Color (4 Pairs) | Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown |
Separator |
Material | PE |
Specification | Translucent 4.5 mm × 0.4 mm (0.1772" ± 0.0157") |
Rip Cord |
Material | Polyester |
Specification | 500D |
Sheath |
Material | PVC |
Min. Average Thickness | 0.5 mm (0.0197") |
Diameter | 6.0 mm ± 0.3 mm (0.2362"±0.0118") |
Color | White |
Electrical |
Max. DC Resistance of a Single Conductor | 8.7 /100 m |
Min. Insulation Resistance | 5000M·km |
Max. DC Resistance Unbalance | 2% (pair intra), 4% (pairs inter) |
Dielectric Strength | No breakdown with 1KV DC for 1 min |
Transmission |
Characteristic Impedance | 100 ± 15 |
Near End Cross Talk | 39.30 dB/100 m @250 MHz |
Max. Attenuation | 34.8 dB/100 m @250 MHz |
Return Loss | 17.3 dB/100 m @250 MHz |
Mechanical |
Tensile Strength | Sheath13.5 MPa, insulation16 MPa |
Elongation at Break | Sheath150%, insulation300% |
Installation Bending Radius | >8 times of outer cable diameter |
Conductor Elongation at Break | 10% |
Environmental |
Shrinkage of Insulation | 5% |
Color Migration Resistance of Insulation | No migration |
Sheath Tensile Strength and Elongation at Break after Aging | 12.5 MPa, 100% |
Low Temperature Bending Test | No cracking after the test |
Heat Shock Test | No cracking after the test |
Operation Temperature | 20°C to +60°C (4°F to 140°F) |
Installation Temperature | 0°C to +50°C (32°F to 122°F) |
Storage Temperature and Humidity | 10°C to +40°C (14°F to 104°F), <60% (RH) |
Security |
Vertical Fire Propagation Test | Comply with IEC 60332-1-2 |
Packaging |
Cable Length | 100.0 m (328.08 ft)±1 m (3.28 ft) |
Inner Carton Dimensions | 286 mm × 119 mm × 289 mm (11.26" × 4.69" × 11.38") (L × W × H) |
Net Weight | 3.8 kg ± 0.3 kg (8.38 lb±0.66 lb) |
Gross Weight | 4.0 kg ± 0.3 kg (8.82 lb±0.66 lb) |
Packaging Dimensions | 595 mm × 310 mm × 270 mm (23.43" × 12.20" × 10.62") (L × W × H) |
Packaging Method | 100 m/carton, 4 inner cartons in one package |
Compliance |
Executive Standards | Q/DXJ 067-2019, EN50575-2014 |
Certification |
Certification | CPR Eca |
