System |
Operation System | Linux |
Language | Multi-language interface: English, Chinese, Spanish, French, German, Turkish, Russian, Czech, Serbian, Portuguese, Polish, Romanian, Hebrew, Japanese, and Persian |
Operation Mode | Button and keyboard |
Auto Standby/Shutdown | Yes |
Keyboard Sound | Enable/Disable |
Screen | 4.0" TFT screen, 800 × 480 resolution |
Keyboard | Controlling keyboard: 13 keys of the main keyboard, and 45 keys of the flip keyboard Others: Power button, reset button |
LED Indicator Light | 2 * 35lm lights |
Update | Online and local update |
IPC Test |
Camera Access | ONVIF |
Resolution | 1MP, 1.3MP, 2MP, 3MP, 4MP, 5MP, 6MP, 8MP, and 12MP |
Camera Initialization | Yes |
Video Display | Live view, snapshots, records, digital zoom, and H.264/H.265 decoding |
Function Control | Support IPC modifications such as resolution, IP, and account password, and restoring IPC to factory settings |
Analog Video Test |
Format | HDCVI, HDTVI, AHD, and CVBS (NTSC, PAL) |
Resolution | HDCVI: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps, 5MP@20 fps, 6MP@20 fps, 4K@12.5 fps/15 fps
HDTVI: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps, 5MP@20 fps
AHD: 2MP@25 fps/30 fps, 4MP@25 fps/30 fps
CVBS: NTSC, PAL |
Function Control | OSD menu display and PTZ control |
Video Display | Live view, snapshots, records, and digital zoom |
Video Signal Generator | Generate PAL and NTSC video test signals Generate HDCVI, HDTVI, and AHD video test signals with 720/1080P |
RS485 Control |
Communication Protocol | More than 30 protocols such as Pelco-D/P, Samsung, Panasonic, Lilin, and Yaan |
Baud Rate | 150 bps, 300 bps, 600 bps, 1200 bps, 2400 bps, 4800 bps, 9600 bps, and 19200 bps |
Protection |
ESD | Air discharge: ±8KV Contact discharge: ±6KV |
Others |
Audio Test | 1 channel audio input test and 1 channel audio output test |
Camera Power Supply | 12V/2A DC power output to the camera |
Network Test | IP address scanning, and Ping test |
Voltage Test | Display voltage, data transmission, and signal strength of PoE/PSE device |
Data Monitor | Receive and display protocol data with a RS485 cable |
Network Cable Test | Test the length and attenuation of a network cable
Test range: 1130 m (3.28426.51 ft) (The maximum length varies depending on the material of the cable) |
Digital Multimeter | Tests of AC/DC voltage, AC/DC current, resistance, capacitance, diode, and circuit conductivity |
Certifications |
Certifications | CE: EN 55032
FCC: FCC Part 15 Subpart B |
Port |
Power | 1 standard PoE charging, IEEE802.3af 1 power output , 12V/2A DC |
Audio | 1 audio input 1 audio output |
USB | 1 USB Mini-B |
Ethernet | 2 RJ45 10M/100M/1G |
RS485 | 1 |
Digital Multimeter Port | 3 |
Power |
Charging | PoE 48V-0.32A |
Battery | Dedicate battery, replaceable, 7.4V polymer lithium ion batteries, up to 22.2Wh, working for about 8 hours |
Enviroment |
Operating Temperature | 10°C to +55°C (+14°F to +131°F) |
Operating Humidity | 30%95% (RH) |
Structure |
Appearance Color | Yellow |
Dimensions | 193.0 × 115.0 × 37.1 mm (7.8" × 4.53"× 1.48") |
Net Weight | 0.54 kg (1.19 lb) |
Gross Weight | 1.40 kg (3.09 lb) |
