> 400x300 VOx uncooled thermal sensor technology
> Athermalized Lens (thermal), Focus-free
> Support Fire detection & alarm
> Various lens optional (13mm)
> 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePoE
Thermal Camera | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Sensor | Uncooled VOx Microbolometer | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Effective Pixels | 400(H)x300(V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Pixel Size | 17um | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Thermal Sensitivity(NETD) | 40mK | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Spectral Range | 8~14um | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Image Setting | Brightness/Sharpness/ROI/AGC/FFC/3D DNR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Color Palettes | 18(Whitehot/Blackhot/Ironrow/Icefire/ Fusion/Rainbow/Globow/Iconbow1/ Iconbow2 .etc) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Thermal Lens | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Lens Type | Fixed/F1.0 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Focus Control | Athermalized, Focus-free
|
Compression | H.265 / H.264 / MJPEG | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Frame Rate | Main Stream: Thermal: 1280x1024 / 720P / 400x300 @25/30fps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sub Stream: Thermal: 640x512 / 400x300 @25/30fps | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate Control | CBR/VBR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Bit Rate | H.264: 640 ~ 8192Kbps | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Motion Detection | Off/On (4 zone, Rectangle) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Region of Interest | Off/On (4 zone) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electronic Image Stabilization (EIS) | NA | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Digital Zoom | 4x(19 levels) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Flip | 180° | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Mirror | Off/On | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Privacy Masking | Off/On (4 area, Rectangle) |
Audio | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Compression | G.711A / G.711Mu / AAC / PCM |
Intelligence | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
IVS | Tripwire, Intrusion | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Advanced Intelligent Functions | Fire detection & alarm, Cold/Hot spot trace, Human/Vehicle classification |
Network | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Ethernet | RJ-45 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interoperability | ONVIF Profile S & G, API | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Streaming Method | Unicast/Multicast | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Max. User Access | 10 Users/20 Users | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Edge Storage | Micro SD (256GB) Memory status display (Normal / Error / Active / Formatting / Lock), NAS (Network Attached Storage), Local PC for instant recording | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Web Viewer | >IE8, | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Management Software | SmartPSS, DSS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Smart Phone | Android, iOS |
Certifications | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certification | CE (EN 60950: 2000) FCC (FCC Part 15 SubpartB ) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Interface | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Interface | 1 Port (CVBS/BNC) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Interface | 1/1 In/Out | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
RS485 | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm | 2/2 In/Out | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Electrical | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | DC 12V/PoE/ePoE | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption |
