The SpeedFace-V5L Series employs intelligent engineering facial recognition algorithms and cutting-edge computer vision technology. It offers support for fingerprint, facial, and palm verification with large capacity and speedy recognition. Moreover, the SpeedFace-V5L is equipped with QR code support via Mobile APP, further enhancing the device's security performance in all aspects.
SpeedFace-V5L Series uses touchless recognition technology and can identify individuals even when wearing masks, making it a hygienic option. Additionally, it has an advanced anti-spoofing algorithm that can detect fake photos and videos. It also features 3-in- 1 palm recognition, which can identify Palm Shape, Palm Print, and Palm Vein in just 0.35 seconds per hand. The palm data is then compared to a maximum of 3,000 palm templates. The facial camera also supports QR codes, Data Matrix, MicroAztec, and other formats, and the ZKBio CVAccess Mobile App supports Dynamic QR codes for T&A/A&C.
The TD/TI Version with mask detection helps reduce the spread of germs and help prevent infections straightly. At each access point of any premises and public areas such as hospitals, factories, schools, commercial buildings, and stations during the recent global public health issue with its masked individual identification function during facial and palm verification.
SpeedFace-V5L Series supports video intercom via the mobile app ZSmart. Also, they are integrated with ONVIF Video protocol to connect to ONVIF NVR for Video surveillance and recording. Moreover, it is compatible with ZKBio Zlink Mobile APP & ZKBio Zlink-Web when switching to BEST protocol. It also supports SIP Protocol connection to the indoor unit.
Model
SpeedFace-V5L; SpeedFace-V5L[TD]; SpeedFace-V5L[TI]
Display
5"@ ISP Color LCD Screen (720*1280)
Camera
WDR Low Light Camera @ 2MP
Operation System
Linux
Hardware
CPU: 1.GHz Dual Core
RAM: 1GB; ROM: 8GB
Supplement Light: Yes
Virtual Keypad: 12 Keys
Fingerprint Sensor: Z-ID
Authentication Method
SpeedFace-V5L: Face / Fingerprint / Palm (Customized) / Card / Password
(Virtual Keypad)
SpeedFace-V5L[TD]: Face / Fingerprint / Palm (Customized) / Card / Password
(Virtual Keypad)
SpeedFace-V5L[TI]: Face / Fingerprint / Palm (Customized) / Card / Password (Virtual Keypad)
Fingerprint Template Capacity
6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) / 6,000 (1:1)
Face Template Capacity
6,000 (1:N) (Standard) / 10,000 (1:N) (Optional) / 6,000 (1:1)
Palm Template Capacity
Customized 3,000 (1:N) (Standard) / 3,000 (1:1)
Card Capacity
10,000 (1:N) (Optional) / 10,000 (1:1)
Transaction Capacity
200,000 (1:N) (Optional for Capacity Expansion)
Biometric Verification Speed
less than 0.3 sec (Fingerprint)
less than 1 sec (Facial Recognition)
less than 0.35 Sec (Palm)
Touchless Biometric Recognition Distance
1cm to 100cm (Facial Recognition)
Up to 50cm(Palm)
False Acceptance Rate (FAR) %
FAR 0.01% ( Visible Light Facial Recognition)
FAR 0.0001% ( Fingerprint ; ZKFingerprint V10.0)
FAR 0.05% (ZKPalm V12.0)
False Rejection Rate (FRR) %
FRR 0.02% ( Visible Light Facial Recognition)
FRR 0.01% ( Fingerprint : ZKFingerprint V10.0)
FRR 1.8% ( ZKPalm V12.0)
Biometric Algorithm
ZKFace 3.9
ArmaturaPalm (Customized)
ZKFingerprint V10.0
Card Type
ID Card@125 kHz (Optional)
IC Card@13.56 MHz (Optional)
CEPAS(Optional)
QR Code
Dynamic or Static QR codes on the ZKBio CVSecurity mobile application. QR code, PDF417, Data Matrix, MicroPDF417 and Aztec scanning in third-party development projects (Support QR500 / 600 Series).
Communication
TCP/IP*1
Wiegand (Input & Output)*1
RS485: ZKTeco RS485*1*
Aux Inputs *1, Aux Outputs *1, Electric Lock*1, Door Sensor*1, Exit Button*1, Alarm*1, Doorbell*1
Standard Functions
ADMS, T9 Input, DST, 14-digit User ID, Access Levels, Groups, Holidays, Anti-passback,
Record Query, Tamper Switch Alarm, Multiple Verification Methods
Power Supply
DC 12V 3A
Operating Temperature
-10°C ~ 45°C (14°F ~ 113°F)
Operating Humidity
10% to 90% RH (Non-condensing)
Dimensions
91.93mm * 202.93mm * 21.5mm (L*W*H)
Gross Weight
1.3 Kg
Net Weight
0.6 Kg
Supported Software
Software: ZKBio CVAccess
Mobile App: ZKBio Zlink / ZSmart
Cloud Service: ZKBio Zlink
Installation
Wall-mount (Compatible with Asian Gang-box / Single Gang-Box)
Certifications
ISO14001, ISO9001, CE, FCC
