Parameters:
The module name: 12A buck perfect version
The modular nature: non isolated buck module
Input voltage: 4.5-30V input voltage should not exceed 30V!!!
Output voltage:1.25-30V continuous adjustable
Output current: 0-12A 100W to strengthen the heat up to 200W,
Working temperature: -40~+85 degrees
Operating frequency: 300KHz
Conversion efficiency: maximum 95%(efficiency is related to the input, the output voltage, current, pressure difference)
Short circuit protection: have (current limiting 14A) please try not to short circuit
Over temperature protection: have (automatic shutdown output ultra temperature)
Input reverse connection protection: No, (such as the need to please series diodes in the input)
Installation: 4pcs 3mm screws
Connection: connecting terminal, without welding, V-IN input, V-OUT output, with the housing mod
