DeepCool CH260 Wood Micro-ATX Gaming PC Case White R-CH260-WHNWM0-G-1
The DeepCool CH260 WOOD WH is a compact Micro-ATX gaming PC case designed for builders who want broad component compatibility without the footprint of a conventional tower. Its white finish, tempered-glass side panel and wood-grain I/O panel create a clean, contemporary appearance, while wraparound mesh ventilation supports effective airflow around demanding components.
Compact Micro-ATX Design
Based on the compact design of the DeepCool CH160, the CH260 expands motherboard compatibility to include Mini-ITX and Micro-ATX boards. It also supports compatible rear-connector Micro-ATX motherboards, with 29.6 mm of clearance behind the motherboard tray to help accommodate rear-facing connections and cable routing.
Natural Wood-Grain Detail
The wood-grain I/O panel introduces a warmer, furniture-inspired detail to the white chassis. Combined with the tempered-glass side panel, it gives completed builds a distinctive appearance that can complement gaming rooms, offices and modern living spaces.
Room for Full-Size Components
Despite its compact format, the CH260 WOOD WH accommodates graphics cards up to 388 mm long when front fans are fitted, or up to 413 mm without front fans. An ATX PS2 power supply up to 150 mm long can be installed using the removable mounting bracket, helping to provide easier access during assembly and cable management.
Flexible Cooling Support
Wraparound mesh panels allow air to move through the compact chassis, while mounting positions for up to six 120 mm fans give builders flexibility when planning their cooling layout. The top of the case supports radiators up to 360 mm, and tower-style CPU coolers up to 174 mm high can be installed.
Convenient Building Features:
- Tool-free front-panel access helps simplify installation and routine maintenance.
- Three removable dust filters make it easier to keep the interior clean.
- Four independent, reusable expansion-slot covers support future component changes.
- Two USB 3.0 ports provide convenient connections for everyday peripherals.
- A USB Type-C Gen 2 port supports compatible modern devices.
- A combined audio and microphone connection keeps headset access within easy reach.
Technical Specifications:
| Specification | Details |
| Brand | DeepCool |
| Model | CH260 WOOD WH |
| Manufacturer Part Number | R-CH260-WHNWM0-G-1 |
| Product Type | Compact Micro-ATX gaming PC case |
| Colour | White with wood-grain I/O panel |
| Materials | ABS, SPCC steel and tempered glass |
| Motherboard Support | Mini-ITX, Micro-ATX and compatible rear-connector Micro-ATX |
| Rear Cable Clearance | 29.6 mm |
| Expansion Slots | 4 |
| Maximum GPU Length | 388 mm with front fans; 413 mm without front fans |
| Maximum CPU Cooler Height | 174 mm |
| Power Supply Support | ATX PS2, maximum length 150 mm |
| Front Fan Support | 2 × 120 mm |
| Top Fan Support | 3 × 120 mm or 2 × 140 mm |
| Rear Fan Support | 1 × 120 mm |
| Pre-installed Fans | None |
| Top Radiator Support | 120, 140, 240, 280 or 360 mm |
| Rear Radiator Support | 120 mm |
| 3.5-inch Drive Bays | 1 |
| 2.5-inch Drive Bays | 1 |
| Front I/O Ports | 2 × USB 3.0, 1 × USB Type-C Gen 2 and 1 × audio/microphone combination port |
| Dust Filters | 3 removable filters |
| Dimensions | 438 × 225 × 312.5 mm (L × W × H) |
| Net Weight | 5.3 kg |
| EAN | 6933412765660 |
Create a compact Micro-ATX gaming system with flexible cooling, full-size component support and distinctive wood-grain detailing by adding the DeepCool CH260 WOOD WH to your cart today.
