Description
Reliable, affordable, and loaded with essential features.
- A dependable and affordable 20" monitor with essential features that meet everyday office demands.
Essential features:
- HD quality display at multiple angles with VESA-mount compatibility and tilt options, as well as VGA and DisplayPort connectivity.
Dependable performance:
- Uncompromising quality testing standards with 3-year warranty and service ensure long-term performance.
Eco-conscious design:
- Save energy with power-efficient features.
An everyday office essential
Screen performance:
- View your applications, spreadsheets and more on 20 inches of 1600x900 HD clarity, with 16.7 million colors, a color gamut of 86 percent gamut and a 170 / 160 horizontal / vertical viewing angle.
Plug and view:
- Compatible with both legacy and current PCs via VGA and DisplayPort connectivity.
Mounting option:
- Keep your desk clutter-free by mounting your VESA compatible monitor on the wall or using the Dell Single Monitor Arm, detailed below.
Tilt at will:
- Work comfortably by tilting the monitor 5 forward or 21 backward.
Convenient controls:
- Easily access buttons for power, brightness, contrast and customizable preset modes on the monitor's front panel.
Eco-conscious and reliable
Peace of mind included:
- Relax knowing that your Dell monitor comes with a 3-year Advanced Exchange Service within its 3-Year Limited Hardware Warranty.
Reduced footprint:
- The Dell 20 Monitor features PowerNap technology that reduces screen brightness or puts the monitor in sleep mode when it's not in use.
- This monitor also meets the latest regulatory and environmental standards:
- ENERGY STAR Qualified
- EPEAT Gold
- CECP Certified
- TCO Certified Displays
Environment-friendly materials:
- Your new Dell monitor is made with arsenic-free glass and a mercury-free LED panel.
- Its circuit boards are made from brominated flame retardant (BFR)- and PVC-free laminates, and it has more than 25 percent post-consumer recycled plastics in its chassis.
Limited Hardware Warranty
- Because it is backed by a 3-Year Limited Hardware Warranty and Advanced Exchange Service, you can purchase your Dell 20 Monitor- E2016H with confidence.
Technical Specifications
Display
Color
- Black
Diagonal Viewing Size
- 19.5 inches
Aspect Ratio
- Widescreen (16:9)
Panel Type, Surface
- TN
Optimal Resolution
- 1600 x 900 at 60 Hz
Preset Display Area (H x V)
- 103602.65 sq-mm (160.4 sq-inches)
Contrast Ratio
- 1000:1 (typical)
Backlight Technology
- WLED
Brightness
- 250 cd/mý (typical)
Response Time
- 5 ms typical (Black to White)
Viewing Angle
- 160 vertical / 170 horizontal
Color Support
- 16.7 million colors
Pixel Pitch
- 0.27 x 0.27 mm
Display Type
- Widescreen Panel Display
Device Type
- Monitor
Display Screen Coating
- Anti-Glare with 3H hardness
Audio Output
- No
Stand
Flat Panel Mount Interface
- VESA (100 mm)
Connectivity
- DP, VGA
Adjustability
- Tilt
Built-in Devices
- N.A.
Security
- Security lock slot (cable lock sold separately)
Overview
Tech Specs
Display
Color
Black
Diagonal Viewing Size
19.5 inches
Aspect Ratio
Widescreen (16:9)
Panel Type, Surface
TN
Optimal Resolution
1600 x 900 at 60 Hz
Preset Display Area (H x V)
103602.65 sq-mm (160.4 sq-inches)
Contrast Ratio
1000:1 (typical)
Backlight Technology
WLED
Brightness
250 cd/mý (typical)
Response Time
5 ms typical (Black to White)
Viewing Angle
160 vertical / 170 horizontal
Color Support
16.7 million colors
Pixel Pitch
0.27 x 0.27 mm
Display Type
Widescreen Panel Display
Device Type
Monitor
Display Screen Coating
Anti-Glare with 3H hardness
Audio Output
No
Stand
Flat Panel Mount Interface
VESA (100 mm)
Connectivity
DP, VGA
Adjustability
Tilt
Built-in Devices
N.A.
Security
Security lock slot (cable lock sold separately)
Dimensions
Height with stand (compressed /extended)
- 368.9 mm (14.52 inches)
Depth
- 167.0 mm (6.57 inches)
Width
- 471.5 mm (18.56 inches)
Height without stand
- 275.4 mm (10.84 inches)
Depth without stand
- 51.5 mm (2.03 inches)
Width without stand
- 471.5 mm (18.56 inches)
Weight (panel only - for VESA mount)
- 2.22 kg (4.89 lb)
Weight (with packaging)
- 4.11 kg (9.06 lb)
Power
Voltage Required
- 100 VAC to 240 VAC / 50 Hz or 60 Hz ñ 3 Hz / 0.8 A (typical)
Power Consumption (Operational)
- 15 W (Typical). 11W (Energy Star)
Power Consumption Standby / Sleep
- Less than 0.3 W
Environmental
Temperature Range Operating
- 0 C to 40 C (32 F to 104 F)
Temperature Range Non-operating
- Storage: -20 C to 60 C (-4 F to 140 F)
- Shipping: -20 C to 60 C (-4 F to 140 F)
Humidity Range Operating
- 10 percent to 80 percent (non-condensing)
Humidity Range Non-operating
- Storage: 5 percent to 90 percent (non-condensing)
- Shipping: 5 percent to 90 percent (non-condensing)
Altitude Operating
- 5,000 m (16,404 ft) (maximum)
Altitude Non-operating
- 12,191 m (40,000 ft) (maximum)
Warranty
- Specifications - Service / Support Details
- 3-Year Advanced Exchange Service
Regulatory
- ENERGY STAR
- EPEAT Gold
- CECP
- TCO
What's in the box
Components:
Monitor panel
Stand (riser and base)
VESA trim cover
Cables:
DisplayPort cable
Power cable
