Smart Monitoring Platform
Thanks to the smart monitoring platform, Deye full series inverter products support remotely shutdown immediately when accident occurs.Setting parameters and FW update remotely, which makes PV plant O&M easier.
Battery Data Battery Type: Lead-Acid or Li-Ion Battery Voltage Range: 40VDC~60VDC Maximum Charging Current: 290A Maximum Discharging Current: 290A UPS Power: 12000W External Temperature Sensor: Yes Charging Curve: 3 Stages / Equalization Charging Strategy for Li-Ion Battery: Self adaption to BMSPV String Input Data Maximum DC Input Power: 20800W Maximum DC Input Voltage: 500VDC Startup Voltage: 125VDC MPPT Voltage Range: 150VDC-425VDC Rated DC Input Voltage: 370VDC PV Input Current: 26A + 26A + 26A Maximum PV (Isc): 44A + 44A + 44A No of MPP Trackers: 3 Strings per MPP Tracker: 2AC Output Data Rated AC Output Power: 16000W AC Output Rated Current: 69.6A Maximum Continuous AC Passthrough: 100A Peak Power (Off Grid): 2 time of rated Power, 5 S Power Factor: 0.8 Leading to 0.8 Lagging Output Frequency and Voltage: 50/60Hz; L/N/PE 220/230VAC (Single Phase) Grid Type: Single PhaseEnvironment Limit Operating Temperature Range: -45°C to 60°C Cooling: Smart Cooling (<30 dB) Communication: RS485 / CAN Ingress Protection: IP65 Safety Certification: IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2
