Digital LCD Display Battery Monitor 8~30VDC

• Input Voltage :8~30V
• Input Current : 5~12mA

User Instructions :

Key operation :

The one white button on the back of the indicator is used to select parameters.

Battery model selection :

Power OFF the Indicator Hold key Power the indicator ON Release button, then the screen will display symbols in English: “XP” or “XC”,x is the number of cells, then users can select batteries model by keys in the following order :

• P1: Pb12V lead-acid battery
• P2: Pb24V lead-acid battery
• C2: 2 pcs lithium batteries
• C3: 3 pcs lithium batteries
• C4: 4 pcs lithium batteries
• C5: 5 pcs lithium batteries
• C6: 6 pcs lithium batteries
• C7: 7 pcs lithium batteries

Note: up to 30V only
