Features:
4.3-inch large clear TFT LCD screen, easy to read and operate.
Fully DVB-S/S2/T/T2/C compliant, satisfying different needs.
Support MPEG2, MPEG4, H.264/MPEG4 AVC, H.265 (10 Bit)/HEVC hardware decoding.
Digital meter for signal strength and quality.
Supports auto scan and manual scan for flexible use.
With sound and light alarm for locking signal.
Able to automatically calculate the angle of AZ and EL.
Supports DISEQC 1.0/1.1/1.2, Unicable, 0/22KHz tone.
Support both AV out and AV in, H-Mi out.
With LNB short-circuit protection for safe use.
Built-in 7.4V/2600mAh large capacity Li-ion battery, which has long operational hours.
Software can be easily upgraded via USB port.
Meter is in compact size and light weight, very easy to carry.
Specifications:
Plug Type: EU / US / UK (Optional)
Material: ABS
Transmission Standards: DVB-S2X/S2/S, DVBT/T2, DVB-C, H.265(10bit)
Item Size: 178 * 140 * 45mm / 7.01 * 5.51 * 1.77in
Item Weight: 612g / 21.60oz
Package Weight: 1029g / 36.29oz
Package Size: 29.8 * 20.5 * 6cm / 11.73 * 8.07 * 2.36in
SATELLITE INPUT/DEMODULATION:
Connector Type: F type
Input Frequency: 950-2150MHz
Signal Input Level: -65~-25dBm
Band Switch Control: 22KHz
LNB Supply: 13V/18V, IMax 400mA
Demodulation Type: QPSK, 8PSK, 16APSK, 32APSK
Symbol Rate: 2
DVB-T/T2/C INPUT/DEMODULATION:
Connector Type: Female type
Input Frequency: 48-862MHz
Signal Input Level: -79.5dBm (DVBT/T2), -67dBm (DVB-C)
ANT Supply: 5V, 12V (+5% ) Imax 100mA
Demodulation Type: QPSK, 16QAM.64QAM, 256QAM
LCD FEATURES:
LCD Type: TFT transmissive
Number of Dots: 800(RGB)*480
Active Area: 95.04 * 53.86mm2 (W*H)
AV OUTPUT INTERFACE:
Connector Type: 3.5mm jack
Video Output: CVBS
Audio Output: Stereo audio L/R output
H*MI OUTPUT CONNECTER:
Format: H*MI 14
AV INPUT INTERFACE:
Connector Type: 3.5mm jack
Video Input: CVBS
Audio Input: Stereo audio L/R input
AUDIO/VIDEO PROCESSING:
Video Decompression: HEVC main prof ile@level 4.1 and main 10 profile@L4.1
Resolving Rate: 480p, 576p, 720p, 1080i/p
Video Format: 4:3, 16:9
Audio Decompression: MPEG-1/2 Layer l/II/III, Dolby AC3/AC3+
Audio Output Mode: Stereo, Mono, R/L
DATA SERVICE PORT:
Connector: USB
Data Protocol: USB2.0 interface
File Management System: NTFS,FAT32
File Format: wma, mp3, mp4, avi, jpg, jpeg, bmp, img
POWER SUPPLY:
Li￢ﾀﾐion Battery: 7.4V, 2600mAh li-ion battery
Adapter: DC12V/1A (output), 100￢ﾀﾐ240VAC 50/60Hz (input)
Power Consumption: Max. 10W
