New function of no-fluid protection! Anti-aging treatment for PCB to support low failure rate!
AC POWER
Input Voltage & Rate: 220-240 V, 50/60 Hz
Current Limiter Type: Fuse (F)
Current Limiter Specifications: 5 A, 250 V
Total Power Consumption: 750 W
Operating Current: 3.1 A
Power Input Connector: Hard-wired
HEATING
Heat Up Time: Appr. 4.5 min
Heater Type: Aluminum Heater Block
CAPACITY
Fluid Tank Capacity : 1.3 L
OUTPUT
Adjustable Volume: ×
Max Output Volume: Appr. 6,400 cuft/min
Max Output Distance : Appr. 3 m
Max Output Duration: Appr. 15 s
Fluid Consumption @ full volume : Appr. 31 min/L
Continuous Output : ×
Fully-loaded Cumulative Output Duration @ full volume: Appr. 40 min
FEATURES
Physical Thermostat:
Electronic Thermo-Control:
Adjustable Output : ×
Adjustable Fan Speed: ×
No-Fluid Protection:
Instant-Stop: ×
CONTROL
On-device Manual Control : N /A
Wireless Control: W-2 / RF 315MHz / External receiver
Wired Control: M-1
Control Protocol: ×
DMX Channel Range: ×
ACCESSORY
Power Cord:
Wireless Controller Model: W-2 / RF 315MHz / Transmitter & Receiver
Wired Controller Model: M-1
CONSUMABLE
Consumable: DJV-001 or D-01 Fog Fluid
WEIGHT & DIMENSIONS
Net Weight: 3.6 kg
Gross Weight: 4 kg
Machine Dimensions: 249 × 249 × 177.1 mm
Packing Dimensions: 300 × 240 × 230 mm
