DSTV Satellite Signal Finder Meter

Works with DSS DirecTV, DishNetwork, ExpressVu, StarBand, DirecWAY, FTA MPEG2 / DVB receivers, plus other digital and analog satellite systems.

Works with C band or KU band satellite signals.

Works with STANDARD, UNIVERSAL, and DSS LNBFs. (Note: Some other competitor brands do not work with UNIVERSAL LNBFs)

950-2150 MHz bandwidth

Pocket size and lightweight

11dB Gain

-25 to -75dBm Input Level

High sensitivity

Built-in light for night dish adjustment

Audible tune-in signal.

Listening to signal tone and changing antenna direction makes it easy and quick to find the best signal reception.

75 Ohms Input/Output impedance

13-18VDC

One of the most useful tools that you can own is this inline signal strength meter. This little device connects between the satellite dish and the receiver and allows you to find the satellite without having to use the meter on your TV. This can be invaluable when you are trying to set up your dish on a tripod a long ways away from your rig. These meters also provide a tone that rises in pitch as the signal strength goes up and a lighted meter for nighttime use.

With one of these meters, it’s often enough to point the dish in approximately the correct azimuth/elevation direction and then slowly sweep the sky and listen for the tone to tell you when you hit the “sweet spot”. These meters are much more sensitive than the one that the receiver provides on your TV and react much faster to changes in signal strength. With a little practice, you’ll be able to find the satellite in seconds and fine tune it quickly.

No batteries required, it is powered by the receiver. It has a built in light and audio tone.

The SF001 works with DSS DirecTV, DishNetwork, ExpressVu, FTA MPEG2 / DVB receivers, plus other digital and analog satellite systems. Works with C band or KU band satellite signals.

Single Package:

1x Satellite Finder

1x Use manual
