Ducati (4.16.10.13.14) Motor Run Capacitor, Metallized PP, Can, 8 µF

Motor Run Capacitor, Metallized PP, Can, 8 µF, ± 5%, 450 VProduct InformationDielectric Type: Metallized PPCapacitor Case / Package: CanCapacitance: 8µFCapacitance Tolerance: ± 5%Capacitor Mounting: -Voltage(AC): 450Vdv/dt Rating: 20V/µsCapacitor Terminals: Wire LeadedLead Spacing: -Height: 55mmProduct Range: 4.16.10Operating Temperature Min: -25°CProduct Height: 55mmProduct Diameter: 32mmOperating Temperature Max: 70°CSeries Name: 4.16.10Product OverviewThe 4.16.10.13.14 is a metalized polypropylene Film Capacitor with wire leadedterminals. The dielectric is polypropylene film, the electrodes consist of anextremely thin metal coating obtained by vacuum evaporation. Case and cover aremade with self-extinguishing plastic material, the capacitive element is sealedwith polyurethane resin.Low losses non-inductive windingSelf-healing property avoiding short circuitsSmall size and limited weightNo leakage riskClass-P0 safety protectionSelf healing property avoiding short circuitsLow losses non inductive windingNo leakage riskApplicationsMotor Drive & Control, Portable Devices, Power Management, Industrial
