Ducati (4.16.10.70.14) Motor Run Capacitor, Metallized PP, Can

Motor Run Capacitor, Metallized PP, Can, 30 µF, ± 5%, 450 VProduct InformationDielectric Type: Metallized PPCapacitor Case / Package: CanCapacitance: 30µFCapacitance Tolerance: ± 5%Capacitor Mounting: -Voltage(AC): 450Vdv/dt Rating: 20V/µsCapacitor Terminals: Wire LeadedLead Spacing: -Height: 92mmProduct Range: 4.16.10Operating Temperature Min: -25°CProduct Height: 92mmProduct Diameter: 40mmOperating Temperature Max: 70°CSeries Name: 4.16.10Product OverviewThe Ducati 4.16.10 series are general purpose, metalized polypropylene filmcapacitor. The polypropylene film acts as a dielectric and electrodes consist ofan extremely thin metal coating obtained by vacuum evaporation. Capacitiveelement is sealed with polyurethane resin. Case and cover are made with selfextinguishing plastic material.Capacitance value ranges from 2µF to 80µFRated voltage of 400V, 425V, 450V, 475V, 500VEndurance of 1000h to 10000h±5% toleranceSmall size and low weightSelf healing property avoiding short circuitsLow losses non inductive windingNo leakage riskApplicationsConsumer Electronics, Portable Devices, Power Management, Industrial
