Specifications:
DVR Specifications:
Operating system: Embedded LINUX
Main function: Live display, Recording, Playback, Remote access
Video display: Single camera or quadrant split screen
Recording frame Rate: 25 FPS Max
Image quality: Low, Normal, High
Modes: - Recording: Continuous / Motion detection - Overwrite: Cycle / Stop on full
Recording Output: MCG
Playback: Single channel / 4 channel simultaneous
RS-485 PTZ control
Wired RJ-45 Ethernet
Hard drive: 500GB HDD included
Input:
- Video: 4 Channel, BNC, 1.0Vp-p, 75 Ohms
- Audio: 2 Channel single AV, Mono
Output:
- Video: 1 channel TV output, BNC, 1.0Vp-p, 75 Ohms
- Audio: 1 Channel single AV
Power supply: 12V, 5A
Working Humidity: 10% to 90%
Dimension (W x W x H): 319 x 227 x 50 mm
Camera Specifications:
It is waterproof
Image sensor: Sharp 1/4 CCD
Resolution: 420 TV Lines
Lens: 3.6 mm
Minimum illumination: 0 Lux( IR LED on )
White balance: Auto
Video output: 1Vp-p, 75ohm, BNC
Shutter speed: 1/50
IR distance: 35 m
IR led: 12 x 3mm LED
Cable length: 18 M
Dimension: dia. 69 x 97 (L) mm
Power supply: 12V, 500mA
Network:
RJ-45 connection port (10 / 100M)
Compression: MJPEG
IP Address: Static / DHCP
Viewing option: Single / 4 channel simultaneous
Remote capture: Image / Video
Capture format: BMP, AVI with Divx codec
IE Explorer Only
Approved: CE / FCC
Accessories:
4 x 18 m Cable
1 x Software CD
1 x User Manual
4 x Mounting Bracket
1 x Remote Controller
1 x Power Supply for DVR
4 x Power Supply for IR Camera
