Application:
The Dyness B4874 rack mount battery module is widely used in energy storage household energy storage systems;
Intelligent Management:
- Dyness is equipped with intelligent BMS for each battery pack to manage modules effectively.
- Compared with the traditional module, B4874 can meet the capacity storage and greatly enhance the cycle life.
Dyness compatability list:
- Victron
- Sacolar (solarway)
- Goodwe
- Imeon
- Solis
- Lux Power
- Sofar
- GMDE
- Growatt
- Voltronic
Specification:
- Nominal Energy: 3.552kWh
- Nominal Capacity: 74Ah
- Nominal Voltage: 48V
- Max. Continuous Discharge Current: 50A
- Max. Continuous Charge Current: 50A
- Charging Cut-Off Vol: 54V
- Discharging End-Off Vol: 40.5V
- Net Weight: 30kg
- Dimensions (W*D*H): 480*360*133.5mm
- Protection Level: IP20
- Calendar Life: 6000 Cycles
- Charging Temperature Range: 0~50ºC
- Discharging Temperature Range: -20~50ºC
- Communication: CAN / RS485
- Configuration: up to 142kWh total energy, 40 modules parallel at most
- Recommend C Rate: 0.5C
- Warranty: 10 years
