Ecco 3.5KVA / 3500W MPPT 100A Hybrid Inverter + 2x 120Ah 12V Gel Batteries | Pure Sine Wave Solar...

Ecco 3.5KVA / 3500W MPPT 100A Hybrid Inverter + 2x 120Ah 12V Gel Batteries | Solar & Backup Power Solution

Description:

The Ecco 3.5KVA Hybrid Inverter combined with two 120Ah 12V Gel Batteries provides an efficient and reliable backup power system for homes and businesses. With MPPT charge controller technology, it offers 30% greater charging efficiency compared to PWM systems, ensuring maximum power utilization from solar panels. This pure sine wave inverter delivers stable and clean power, making it ideal for sensitive electronic devices while ensuring uninterrupted power supply during outages.

• Multiple Output Priority Modes:
  • UTL (Utility First) Prioritizes grid power.
  • SOL (Solar First) Maximizes solar energy usage.
  • SBU (Solar & Battery First) Ideal for off-grid applications.

• Key Features:

  • Hybrid Functionality: Supports grid, solar, and battery power for versatile energy management.
  • Pure Sine Wave Output: Ensures stable, high-quality power for sensitive electronics.
  • MPPT Solar Charger (100A): Maximizes solar panel efficiency for improved performance.
  • Wi-Fi Monitoring (Optional): Connect a Wi-Fi dongle (sold separately) for remote monitoring.
  • High Power Output: 3.5kVA / 3500W capacity supports demanding appliances and devices.
  • Wide Solar Voltage Range: Compatible with solar arrays up to 500VDC.

  Technical Specifications:

  Inverter Mode:

  • Rated Power: 3500VA / 3500W
  • DC Input: 24VDC (158A)
  • AC Output: 230VAC, 50/60Hz (15.2A)

  AC Charger Mode:

  • AC Input: 230VAC, 50/60Hz (23.5A)
  • DC Output: 27VDC
  • Max Charge Current: 80A
  • Max Combined Charge Current (AC + PV): 100A
  • AC Output: 230VAC, 50/60Hz (15.2A)

  Solar Charger Mode:

  • Max PV Array Power: 4000W
  • Min Solar Voltage: 60VDC
  • Max Solar Voltage (VOC): 500VDC
  • Max Charge Current: 100A

  Physical Specifications:

  • Dimensions: 359mm x 295mm x 100mm
  • Weight: 7kg

Battery Specifications (2x 120Ah 12V Gel Batteries):

• Type: Sealed Lead Acid Gel Battery
• Voltage: 12V
• Capacity: 120Ah per battery (Total: 240Ah)
• Weight: 22.7kg per battery
• Dimensions: 420 x 185 x 265mm
• Battery Warranty: No manufacturer warranty

What's Included in the Package:

• 1x Ecco 3.5KVA / 3500W 24V MPPT Hybrid Inverter
• 2x 120Ah 12V Gel Batteries
• User Manual

Optional Add-On:

• Ecco Hybrid Inverter Wi-Fi Dongle (For remote system monitoring)

Important Notes:

• Battery cables are NOT included.
• Installation must be performed by a qualified wireman or master electrician.
• A valid Certificate of Compliance (COC) is required for warranty claims.
• Warranty claims without professional installation proof, installation photos, or a valid COC may be rejected.

Ideal For:

• Load shedding and power backup systems
• Small business and home solar solutions
• Off-grid and hybrid solar applications
• Energy storage for solar panels

Installation & Warranty Information:

• Inverter Warranty: 5-Year Repair Warranty
• Battery Warranty: 90 days replacement

• WOULD YOU LIKE TO ADD A WIFI DONGLE FOR YOUR ECCO INVERTER:
