Voltage Per Unit | 12 V |
Capacity | 17 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) |
Weight | Approx. 5.67 kg. (12.50 lbs.) |
Maximum Discharge Current | 230A (5 sec) |
Internal Resistance Approx. | Approx. 16.5mΩ |
Operating Temperature Range | Discharge¯¼Â-15¢~50¢Â(5°F~122°F) Charge¯¼Â-15¢~40¢Â(5°F~104°F) Storage¯¼Â-15¢~40¢Â(5°F~104°F) |
Nominal Operating Temperature Range | 25°C ± 3°C (77°F ± 5°F) |
Float Charging Voltage | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
Recommended Maximum Charging current limit | 5.1A |
Equalization and Cycle Service | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
Self Discharge | CSB Batteries can be stored for more than 6 months at 25°C (77°F) Please charge batteries before using. For higher temperatures the time interval will be shorter. |
Terminal | B1/B3-L terminal to accept M5 nut & bolt |
Container Material | ABS(UL94-HB/File E50263)*Flammability resistance of(UL94-V0/File E88637) can be available upon request. |
 |
