Electronic Analog Multiplexer Demultiplexer Module HC4051A8 8 Channel Switch Module 74HC4051 Board

Features: ? 1. Wide analog input voltage range from -5 V to +5 V. 2. The low on-resistance has three typical value of different VEE. 3. Logic level conversion: enables 5 V logic to communicate with ±5 V analog signal. 4. ESD protection: HBM JESD22-A114F exceeds 2000 V; MM JESD22-A115-A exceeds 200 V; CDM JESD22-C101E exceeds 1000 V. 5. The HC4051A8 is a single-pole, eight-throw analog switch (SP8T) for analog or digital 8:1 multiplexer/demultiplexer applications. 6. The switch has three digital select inputs (S0, S1 and S2), eight independent inputs/outputs (Yn), one common input/output (Z) and one digital enable input (E). 7. When E is high, the switch is turned off. The input includes a clamp diode. This enables the use of a current limiting resistor to connect the input to a voltage that exceeds VCC. ? Specification: ? Input Analog Voltage:-5~+5V Low On-Resistance: - VCC is 80?? (typical) - VEE = 4.5 V. - VCC is 70?? (typical) - VEE = 6.0 V. - VCC is 60?? (typical) - VEE = 9.0 V. Logic Level Translation: Communicate 5 V Logic with ±5 V Analog Signals. Break before Close:Built-In ESD protection: - HBM JESD22-A114F exceeds 2000 V. - MM JESD22-A115-A exceeds 200 V. - CDM JESD22-C101E exceeds 1000 V. Size:27.94 x 17.78 x 3.3mm / 1.1 x 0.7 x 0.13in(Apply to bread board) Weight: 1.8 g / 0.06 oz(approx.) ? Applications: ? For Breadboard Suitable For MEGA2560 For MCU ARM AVR ADC For Raspberry Pi For PLC RS485? For Analog Acquisition Analog Multiplexing And Demultiplexing Digital Multiplexing And Demultiplexing Signal Gating ? Package Included: ? 1 x Analog Multiplexer Demultiplexer Module ? ?
