Name: ELM327 Bluetooth OBD2 OBDII Car Diagnostic Interface Scanner Tool
SKU: 1188966
Price: 289.64 ZAR
Availability: SoldOut

ELM327 Bluetooth OBD2 OBDII Car Diagnostic Interface Scanner Tool

New

10 were available

R289.64

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 15 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

click and buy2136

96.64 % Positive ratings

Buyer protection

How you're covered

Get it now, pay later

Condition

New

Location

International

Product code

1188966

Bob Shop ID

357583237

Feature:
1.Small size, compact structure. Plug and never unplug
2.Stable wireless connection
3.No wires or batteries (adapter is powered by the diagnosis size sockets)
4.Stop communication, wait half an hour, auto sleep
5.Supports all OBD2 (OBD II) protocols
6.The adapter uses the fastest and most reliable ARM chips
7.The device is a small adapter that plugged into the vehicle OBD-connector. On Bluetooth, it connects to any computer, tablet or smartphone, with associated diagnostic procedures.
8.Measure the fuel consumption
9.Display real-time operating performance of the car, such as momentum, vehicle speed, oil pressure, coolant temperature, engine load, intake manifold pressure, throttle position, the values of oxygen sensors, air intake temperature, and more
10.Turn off the MIL (signal Check Engine)
11.Download data to external media in a variety of formats for later printing
12.Record various parameters, display graphics in real time, and more

Specification:

Color	Red, White, Green, Orange
Supply voltage(VDD)	12V
Work temperature range	-20 ~ +70￢ﾄﾃ
Storage temperature range	-40 ~ +125￢ﾄﾃ
RF sensitivity(Basic Rate)	-85db
Modulation Mode	GFSK
Frequency Range	2402 ~ 2480MHZ
Transmission Range	10M
Bluetooth Profile	SPP
UART Params	38400, 8, n, 1

Protocals:
0.Automatic
1.SAE J1850 PWM(41.6Kbaud)
2.SAE J1850 VPW(10.4Kbaud)
3.ISO9141-2(5 baud init,10.4Kbaud)
4.ISO14230-4 KWP(5 baud init,10.4 Kbaud)
5.ISO14230-4 KWP(fast init,10.4 Kbaud)
6.ISO15765-4 CAN(11bit ID,500 Kbaud)
7.ISO15765-4 CAN(29bit ID,500 Kbaud)
8.ISO15765-4 CAN(11bit ID,250 Kbaud)
9.ISO15765-4 CAN(29bit ID,250 Kbaud)
A.SAE J1939 CAN(29bit ID,250*Kbaud)
B.USER1 CAN(11*bit ID,125*Kbaud)
C.USER2 CAN(11*bit ID,50*kbaud)
*default settings(user adjustable)

Package Included:
1 X KW902 Bluetooth ELM327 OBD2 Scan Tool
1 X User Manual
