Specifications:
Brand: Geprc
Model: TAKER F411 8Bit 12A AIO
Item Name: F4 Flight Controller Built-in 12A 4in1 ESC
Optional Version: ELRS 2.4G ( Built-in ELRS 2.4G Receiver) / Without Receiver ( Don't have receiver)
MCU: STM32F411
IMU: ICM42688P
Firmware target: GEPRC_F411_SX1280
OSD: BetaFlight OSD w/ AT7456E chip
UART Ports: R1 T1R2 T2
Reverse Port: NR2
Buzzer: YES
LED: YES
USB Port: micro USB
ESC MCU: BB21F16G
Black Box: 16Mb onboard flash memory
Continuous Current: 12A
Peak Current: 13A
Input: 2-4S
ESC Protocol: Dshot300,Oneshot,Multishot
Current Meter: 210
ESC Firmware: G-H-30 — Bluejay, 0.16, 48kH
Size: 31.2×31.2mm Board
Mounting holes: 25.5mm*25.5mm hole, M2 hole
Weight: 7g
Features:
Ultra-Lightweight Design: The TAKER F411 8Bit 12A AIO is incredibly lightweight, with the integrated board weighing o
