Apply Enciromental Condition:
Storage temperature range: -20°C-65°C
Operating temperature range: -10°C-55°C
Operating voltage range: 4.8V-6V
Electrical specification:
Operating speed(at no load)
0.13sec/60 (4.8v)
0.11sec/60 (6v)
Running curret(at no load)
250mA Max (4.8v)
300mA Max (6v)
Stall torque
1.8kg.cm Max (4.8v)
2.1kg.cm Max (6v)
Maximum current
0.8A Max (4.8v)
1.0A Max (6v)
Idle current
7.4mA (4.8v)
7.4mA (6v)
Mechanical specification:
Overall Dimensions: As picture
Weight: 12.3±0.5g
Connector wire gauge: JR
Connector wire length: 250±8
Flower head: 15T
Bearing: NO
Gear type: 3 metal gear+3 plastic gear
Extreme angle: 360°
