Enhanced Version 5A High Current DC-DC Step Down Power Module 5-38V To 1.25-36V

20 available / new

R377.00

Add to watchlist Watch

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

szulou3515

93.45 % Positive ratings

Buyer protection

How you're covered

Returns

Replacement Guarantee: 7 Days: We stand by this guarantee

Get it now, pay later

Product details

Condition

New

Location

International

Bob Shop ID

643379006

Description:

Module Properties: Non-Isolated Buck Module (BUCK)
Input voltage: 5-38V (Do not exceed 40V)
Output voltage: 1.25-32V continuously adjustable (default output 5V)
Output current: 0-5A (long-term 4A) 50W
stand-by current: 10mA
Output ripple: 30mV minimum
Working temperature: -40~+85 degrees
Operating frequency: 180KHz
Conversion efficiency: up to 95% (efficiencies related to input, output voltage, current, differential pressure)
Short circuit protection: Yes (limited current 8A)
Over-temperature protection: Yes (automatic shutdown output after over-temperature)
Reverse input protection: Yes
Installation method: 4 pieces of 3mm wire
Connection mode: Terminal IN is input, OUT is output
Module size: 60mmx30mmx13.5mm(length x width x height)

Package included:

1 xEnhanced Version 5A High Current DC-DC Step Down Power Module
