Epcos (B32332I6206J081) Motor Run Capacitor, Metallized PP, Can

Motor Run Capacitor, Metallized PP, Can, 20 µF, ± 5%, Stud Mount - M8, 450 VProduct InformationDielectric Type: Metallized PPCapacitor Case / Package: CanCapacitance: 20µFCapacitance Tolerance: ± 5%Capacitor Mounting: Stud Mount - M8Voltage(AC): 450Vdv/dt Rating: -Capacitor Terminals: Quick ConnectLead Spacing: -Height: 93mmStud Size - Metric: M8Product Range: B32332Operating Temperature Min: -25°CProduct Height: 93mmOperating Temperature Max: 85°CProduct Diameter: 30mmSeries Name: B32332Product OverviewThe B32332I6206J081 is a Motor Run Capacitor with quick connect, snap-in doublefast-on terminals. UL94-V2/V0 top/IEC 60335-1 aluminium can with M8 bolt andplastic top, metalized polypropylene film and soft polyurethane resin. The SuperMotorCap B32332 series AC film capacitor is suitable for general sine waveapplications.Self-healing propertiesLow dissipation factorHighest safety level P2 to IEC 60252-1 2001-02Overpressure disconnection deviceHigh insulation resistanceApplicationsMotor Drive & Control
