Epcos (B32654A4225J000) General Purpose Film Capacitor, Metallized PP

General Purpose Film Capacitor, Metallized PP, Radial Box - 2 Pin, 2.2 µF, ± 5%,200 V, 400 VProduct InformationDielectric Type: Metallized PPCapacitor Case / Package: Radial Box - 2 PinCapacitance: 2.2µFCapacitance Tolerance: ± 5%Voltage(AC): 200VVoltage(DC): 400VCapacitor Mounting: Through HoleCapacitor Terminals: PC PinHumidity Rating: GRADE II (Test Condition A)Lead Spacing: 27.5mmProduct Length: 31.5mmProduct Width: 14mmProduct Height: 24.5mmProduct Temperature Min: -55°COperating Temperature Max: 110°CQualification: AEC-Q200Product OverviewThe B32654A4225J000 is a metalized polyester Film Capacitor with lead-freetin-plated parallel wire lead terminals. Polypropylene (PP) dielectric, plasticcase (UL94V-0) and epoxy resin sealing. Suitable for electronic ballasts andhigh pulse (wound) applications.High pulse strengthHigh contact reliabilityHalogen-freeApplicationsPower Management, Medical
