Epcos (B82464G4222M000) Power Inductor (SMD), 2.2 µH, 6.5 A, Shielded

Epcos (B82464G4222M000) Power Inductor (SMD), 2.2 µH, 6.5 A, Shielded

New 71 available
R165.00
Shipping
R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate
The seller has indicated that they will usually have this item ready to ship within 7 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery
Main centres:  1-3 business days
Regional areas: 3-4 business days
Remote areas: 3-5 business days
Seller
Buyer protection
Get it now, pay later

Product details

Condition
New
Location
South Africa
Product code
7429401
Bob Shop ID
674502801
Power Inductor (SMD), 2.2 µH, 6.5 A, Shielded, 7 A, B82464G4, 10.4mm x 10.4mm x4.8mmProduct InformationInductance: 2.2µHRMS Current (Irms): 6.5AInductor Construction: ShieldedSaturation Current (Isat): 7AProduct Range: B82464G4Power Inductor Case: 10.4mm x 10.4mm x 4.8mmDC Resistance Max: 0.01ohmInductance Tolerance: ± 20%Product OverviewThe B82464G4222M is a surface mount shielded Power Inductor with ferrite core.This B82464G series magnetically shielded inductor features enamel copper wireand winding welded to terminals. This inductor's terminals are made of CuFe2Pbase Ag/Sn layer and electro-plated terminals. Supports 0.1MHz frequency and±20% of inductance tolerance. It is suitable for reflow soldering.High rated currentLow DC resistanceQualified to AEC-Q200 standard
Add to cart
