Esener 5.5KVA / 5500W Hybrid Inverter (MPPT 100A) + 51.2V 100Ah Lithium Battery / Complete Solar ...

Esener 5.5KVA / 5500W Hybrid Inverter (MPPT 100A) + 51.2V 100Ah Lithium Battery / Complete Solar Power Kit

Product Description:

The Esener 5.5KVA Hybrid Inverter, combined with a 51.2V 100Ah Lithium Iron Phosphate (LiFePO4) Battery and four 460W solar panels, provides a powerful, efficient, and scalable solar energy solution. This system is designed for residential, business, and off-grid applications, offering high-efficiency solar energy conversion and seamless power backup.

With a built-in MPPT 100A charge controller, this inverter enhances solar energy harvesting, delivering up to 30% higher efficiency compared to PWM controllers. The parallel functionality allows multiple inverters to be linked for expanded power capacity.

Key Features:

Hybrid Inverter Features:

• Pure Sine Wave Output Provides clean and stable power for sensitive electronics.
• Power Factor 1.0 Maximizes energy conversion efficiency.
• Built-in MPPT 100A Charge Controller Enhances solar energy harvesting and battery charging efficiency.
• Battery-Free Operation Can power loads directly from solar energy without requiring a battery.
• High PV Voltage Support:
  • PV Input Voltage Range: 120V - 450V DC
  • Nominal PV Operating Voltage: 280V - 360V DC
  • Maximum PV Power Input: 5500W
• User-Adjustable Settings:
  • Charge current and voltage customization
  • Multiple output priority modes (UTL, SOL, SBU, SUB)
• Parallel Connection Support:
  • Expand up to 12 inverters for increased power output
  • Compatible with single and three-phase configurations
• RS485 Communication for Battery Management Systems (BMS) Integrates seamlessly with popular inverter brands like Growatt, SOLAX, DEYE, MUST, Victron, and more.
• Automatic Transfer Switching:
  • 10ms transfer time for computers and sensitive loads.
  • 20ms transfer time for general appliances.
• Wi-Fi / GPRS Remote Monitoring (Optional Dongle Sold Separately) Enables real-time tracking of system performance.
• Overload and Short Circuit Protection Enhances system safety and longevity.

Technical Specifications:

Inverter Specifications:

• Rated Power Output: 5.5KVA / 5500W
• Battery Voltage: 48V DC
• AC Input Voltage: 230V AC
• Frequency Range: 50Hz / 60Hz (Auto-Sensing)
• Output Voltage Regulation (Battery Mode): 230V AC ±5%
• Surge Power: 11,000W
• Peak Efficiency: 93%
• Waveform: Pure Sine Wave

Battery & AC Charger:

• Floating Charge Voltage: 54V DC
• Overcharge Protection Voltage: 63V DC
• Maximum Charging Current: 100A

Solar Charge Controller:

• Maximum PV Array Open Circuit Voltage: 450V DC
• Maximum Solar Charging Current: 100A

Physical Dimensions:

• Inverter Size: 480 x 290 x 113mm
• Inverter Weight: 10kg

Battery Specifications (Esener 51.2V 100Ah 5.12kWh Lithium Battery):

• Type: Lithium Iron Phosphate (LiFePO4)
• Nominal Voltage: 51.2V
• Capacity: 100Ah (5.12kWh)
• Cycle Life:
  • Up to 6,000+ cycles at 80% Depth of Discharge (DOD)
  • Retains 80% capacity after extended use
• Charge & Discharge Performance:
  • Maximum Continuous Charge Current: 100A
  • Maximum Continuous Discharge Current: 100A
• Operating Temperature Range:
  • Charge: 0°C to 50°C
  • Discharge: -10°C to 50°C
• Built-in Battery Management System (BMS):
  • Overcharge, over-discharge, and over-temperature protection
  • Communication via CAN Bus and RS485
• Installation: Wall-mount or shelf rack compatible
• Lightweight Construction: 40% lighter than lead-acid batteries
• Weight: 46kg
• Dimensions: 505 x 162 x 543mm
• Parallel Connection: Supports up to 15 battery packs
• Certifications: CE, UN38.3, IEC, MSDS
• Design Life: 15 years
• Warranty: 5-Year Manufacturer's Warranty

What's Included in the Package:

• 1x Esener Hybrid Inverter 5.5KVA / 5500W 48V (MPPT 100A, Pure Sine Wave, Parallel Ready)
• 1x Esener 51.2V 100Ah 5.12kWh Lithium Iron Phosphate Battery
• 1x Set of Battery Cables & Mounts
• 1x Ethernet Communication Cable
• 1x User Manual
• 1x Wall Mount Bracket
• 1x Warranty Card
• 1x Wi-Fi Dongle (Optional for Remote Monitoring)

Important Notes:

• Solar panels are couriered at the buyer's risk.
• It is recommended to use Esener batteries for guaranteed performance.
• Installation must be performed by a qualified wireman or master electrician.
• A valid Certificate of Compliance (COC) is required for warranty claims.
• Warranty claims without professional installation proof, installation photos, or a valid COC may be rejected.
• Damage due to improper use or burning out of the unit is not covered under warranty.

Ideal For:

• Load shedding and emergency backup power
• Small business and home solar energy systems
• Off-grid and hybrid solar energy storage
• Reliable power backup for essential appliances

Inst...
