ESP32-CAM-MB WiFi OV2640 Camera Module Bluetooth Module 5V CH340G Nodemcu FT232RL USB to TTL Convert

The -ESP32-CAM-MB module is a small camera module.This module can work independently as the smallest system.A new WiFi+Bluetooth dual-mode development board based on ESP32 design, using PCB on-board antenna, with 2 high-performance 32-bit LX6CPU, using 7-level pipeline architecture, main frequency adjustment range 80MHz to 240Mhz.Ultra-low power consumption, deep sleep current is as low as 6mA. It is an ultra-small 802.11b\/g Wi-Fi + BT\/BLE SoC module-ESP32-CAM-MB adopts Micro-USB interface, convenient and reliable connection , convenient to apply to IoT hardware terminal occasions.Built-in 520 KB SRAM, external 8MB PSRAMSupport UART\/SPI\/I2C\/PWM\/ADC\/DAC and other interfacesSupport OV2640 and OV7670 cameras, built-in flashSupport picture WiFI uploadSupport TF cardSupport multiple sleep modes.Embedded Lwip and FreeRTOSSupport STA\/AP\/STA+AP working modeSupport Smart Config\/AirKiss one-click network configurationSupport secondary developmentApplication scenarioHome smart device image transmissionWireless monitoringSmart agricultureQR wireless recognitionWireless positioning system signalAnd other IoT applicationsSpecificationsWorking voltage 4.75-5.25VSPIFlash default 32MbitRAM internal 520KB + external 8MB PSRAMWi-Fi 802.11b\/g\/e\/iBluetooth Bluetooth 4.2BR\/ and BLE standardSupport interface (2Mbps) UART, SPI, I2C, PWMSupport TF card, maximum support 4GIO port 9Serial port rate default 115200bpsSpectrum range 2400 ~2483.5MHzAntenna form Onboard PCB antenna, gain 2dBiImage output format: JPEG (only OV2640 support), BMP, GRAYSCALEColour:blackMaterial:plasticPackage Contents:1 * ESP32 WiFi + Module1 * ESP32 USBBoard1 * OV2640 camera1 * USB to TTL Serial Converter1 * 20cm 40pin Female-Female Jumper WiresOnly the above package content, other products are not included.Note: Light and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +\/- 1-3cm.
