ESQUIRE Barcode Laser Scanner ¿32-bit Decoding Technology , Scan Patten Single scan line , High-Sensitivity Laser Scan Engine , Scan Speed:200 scan/sec , Depth of Field: 3~55 cm , Cable Length 180cm, Retail Box , 1 year Limited Warranty
Product Overview
The ESQUIRE Hand-held Barcode Laser Scanner with 32-bit Decoding Technology, a Scan Speed up to 200 scans per second and the depth of scan field can be between 3cm to a maximum of up to 55cm is designed for Retail POS , Hospitality and Medical distribution facilities for managing the flow of materials, production and inventory management, it features an unprecedented combination of superior performance and rugged ergonomic design of a high-end POS scanner and an affordable price.
This USB Ver 2.0 interface Laser scanner that is manufactured by Tysso uses a laser diode beam as the light source to scan the laser beam back and forth across the bar code for accuracy. Easy to use with a simple installation and ideal use in a wide range of situations and workplaces
Highlights ¿ High-Sensitivity Laser Scan Engine
¿ Sensor Type-Laser diode
¿ Scan Speed: 200 scan/sec
¿ Wavelength-650 nm±10 nm
¿ Depth of Field: 3~55 cm(max)
¿ Contrast Ratio->30%
¿ Scan Patten-Single scan line
¿ Resolution-0.1 mm (4 mil) max.
¿ 32-bit Decoding Technology
¿ Ergonomic Design and Durable Housing
¿ NO Auto Scan
¿ Cable Length 180cm
¿ Interface: USB Ver 2.0 Interface
Readable Bar Code Symbologies
EAN-8/JAN-8, EAN-13/JAN-13, UPC-E, Code-128, CODE-93, RSS-Standard, RSS-Limited, RSS-Expanded, CODE-39, Inter-Leaved 2/5, Inter-Standard 2/5, Matrix 2/5, Industrial 2/5, China-Post, MSI, MSI-PLESSEY, CODE-BAR, CODE-11
Specifications
¿ Stock Code GS-6000
¿ Description ESQUIRE Hand-Held Barcode Laser Scanner- USB Interface
¿ Manufacturer ¿Tysso
¿ Scan Rate-200 scans/sec
¿ Sensor Type-Laser diode
¿ Wavelength-650 nm±10 nm
¿ Depth of Field-3~55 cm max
¿ Contrast Ratio->30%
¿ Scan Patten-Single scan line
¿ Resolution-0.1 mm (4 mil) max.
¿ System Interface-USB
¿ Indicator-Buzzer and LED illumination
¿ Auto Scan-No
¿ Power Input-5VDC ±5%
¿ Operation Mode-50 mA(100 mA max)
¿ Power-5V DC via cable
¿ Material-ABS
¿ Colour-Grey
¿ Shock Resistance-1.5m drop onto concrete
¿ Cable Length-180 cm, exchangeable
¿ Ambient Light-Daylight 4800 Lux
¿ Operating Temperature--10°C~50°C
¿ Storage Temperature--20°C~60°C
¿ Storage Humidity-5% ~ 95% RH (non-condensing)
¿ Dimension (L x W x H:mm)-170.5 x 68.5 x 90.6
¿ Weight-approx. 238 g (with cable)
