Ethernet SHDSL Extender - Westermo DDW-220 Wolverine Series

Westermo DDW-220 Wolverine Series Ethernet SHDSL Extender

Extends Ethernet Network up to 10km

The DDW-220 is an Industrial Ethernet SHDSL extender with a built-in Ethernet switch.
It is designed as a transparent Ethernet Extender for 10/100BaseTX networks.

SHDSL represents the best of several symmetric DSL technologies. This unit provides the ability to reuse existing twisted copper pair with data rates from 192 kbit/s to 5.7 Mbit/s in both directions. The DDW-220 makes it possible to communicate over 6.2 miles (10 km) on twisted pair cable.

The DDW-220 is a bridge not router and so is simple to install. All configuration is done using a web interface.

The DIN rail mounted DDW-220 is designed for harsh environments and can be used in industrial and railway applications. It can be powered from two separate supplies and handle an operating voltage range of 16 – 60 VDC

- 192 kbit/s to 5.7 Mbit/s
- Over 10 km on twisted pair
- Multidrop SHDSL applications
- Wide temperature range (–40 to +85°C) (–40 to 185°F)
- Total galvanic isolation & transient protection
- Industrial and Rail EMC approvals
- Redundant power and wide DC input range
- Configuration using web interface
- Integrated 4-port Ethernet switch with 10/100Base-T/TX
- Auto MDI/MDI-X … Auto speed on SHDSL with reliable, normal or high-speed mode
- Comprehensive diagnostics
 -- SHDSL
 -- Ethernet port statistics
- SNMP support
- Extensive line protection with over-current / voltage suppression

More info:
www.westermosales.com/pdfs/DDW-220manualENG.pdf

Shipping info: Item weight: 1.9 kg when packed.
