Specification:
Input: AC100-240V@MAX30W
Battery Type: LiPo LiHV LiFe @1-4S
Charging Power: 0.5-2.5A@25W
Bal Cur. : 200mA @2-4S
Charging accuracy: <0.005V
Display: LCD IPS 1.54 inch 240*240 resolution
Size: 75mm*54mm*30mm
Weight: 120g
Connector: XT30
Suitable for 4S 350mAh~850mAh LiPo Battery. For the bigger battery, please choose the ISDT Q6 NANO
Using Instructions
Connect the power cordand after booting enter the main interface
Press and hold the button for 2 seconds to select the battery cut-off voltage.
Press the button once to select the charging current.
Connected to the battery main port and balance portthe charger will automatically start charging after detecting that the battery voltage is normal.
After ea
