Excellway MC4 Solar PV Diode Connector10A/15A 1000V Waterproof Diode Holder For ... (CURRENT: 10A)

20 available / new

R405.00

Shipping

R35.00 Standard shipping using one of our trusted couriers applies to most areas in South Africa. Some areas may attract a R30.00 surcharge. This will be calculated at checkout if applicable.
Check my rate

The seller has indicated that they will usually have this item ready to ship within 12 business days. Shipping time depends on your delivery address. The most accurate delivery time will be calculated at checkout, but in general, the following shipping times apply:

Standard Delivery

Main centres:	1-3 business days
Regional areas:	3-4 business days
Remote areas:	3-5 business days

Seller

szulou3465

93.42 % Positive ratings

Buyer protection

How you're covered

Returns

Replacement Guarantee: 7 Days: We stand by this guarantee

Get it now, pay later

Condition

New

Location

International

Bob Shop ID

641123949

SELECTED OPTION:
CURRENT: 10A

Feature:
-- Cable connector is riveted and fastened -- Strong anti-aging, anti-UV function, in line with the harsh outdoor conditions
-- Male and female connectors are easy to plug and unplug, no need to use any tools, plugging and unplugging is not easy to damage buckle is a good helper for PV distributed small systems.

Specification:
Cable type: Adapter Interface type: DC/DC Support card number: 2-in-1 card type: CF II shape: Rectangle Features: Waterproof Working frequency: Low frequency Contact material: Tinned copper insulator Material: Ppo Number of cores: 1 Number of stitches: 1 Photovoltaic connector: Solar photovoltaic connector with protection function

Technical Data
Rated current	10A 15A (According to the FUSE)
Degree of protection	IP2*/IP67
Retaed voltage	1000V DC
Test voltage	6000V(50Hz,1min)
Flame class	UL94-V0
Insertion force/withdrawal force	a50N/a50N
Contact resistance of plug connectosr	0.5m
Insulation material	PPO
Temperature range	-40~+125a
Contact material	Copper,Ag Plated
Connecting System	Crimp connection
Safety class	II
Overvoltage category/Polution degree	CATIII/2
