60 Visual Coverage
- Your surroundings are covered with this outdoor pan/tilt camera. With a 352 horizontal rotation and 95 vertical rotation, the C8C gives you an easy overview of all that's around you. And the EZVIZ app puts it all right on your smartphone or mobile device.
AI-Powered Person Detection
- Built-in AI algorithm does not require an additional subscription and allows C8C to identify human activity to ensure alerts are relevant to your home's security.
Smart Spotlight Colour Night Vision
- C8C can actively monitor in the dark in black and white, and automatically turn on spotlights and colour night vision when human movement is detected.
- Select between three modes on the EZVIZ APP : Full black and white night vision (spotlights off), full colour night vision (spotlights on), and smart colour night vision (spotlights auto activate when human movement is detected).
Strobe Light for Enhanced Protection & IP 65 Weatherproof
- Coming with two spotlights for active protection, the camera allows you to manually flash the light via the app or set it to flash upon detection of people passing by
- Its weatherproof design keeps it operating wthout being interrupted by any kind of weather - wind, rain or snow.
One-way Audio
- The built-in noise canceling microphone picks up clear audio and lets you hear and see what's happening in your back yard wherever you are.
H.265 Video Technology
- The C8C features the advanced H.265 video compression technology, achieving better video quality with only half the bandwidth and half the storage space of the previous video compression standard (H.264).
Optional Storage
- Supports up to 256GB SD card (sold separately). Or try EZVIZ Cloud subscription. All data traffic between device/App to the server is stored with AES 128bit encryption . EZVIZ has been awarded ISO/IEC29151:2017 Personal Data Privacy Protection Management System Certification.
Specifications
Model CS-C8C (1080P)
Camera
Image Sensor 1/2.7" Progressive Scan CMOS
Shutter Speed Self-adaptive shutter
Lens 4mm @ F1.6, view angle: 87 (Horizontal), 105 (Diagonal) 6mm @ F1.6, view angle:55 (Horizontal), 66 (Diagonal)
PT Angle Pan: 352, Tilt: 95
Minimum Illumination 0.5 Lux @(F1.6, AGC ON), 0 Lux with IR
Lens Mount M12
Day & Night IR-cut filter with auto-switching
DNR 3D DNR
WDR Digital WDR
BLC Supports
Black & White Night 30 m
Video & Audio
Max. Resolution 1920 1080
Frame Rate Max:30 fps; Self-Adaptive during network transmission
Video Compression H.265 / H.264
Video Bit Rate Ultra-HD; Hi-Def; Standard. Adaptive bit rate.
Audio Bit Rate Self-Adaptive
Max. Bitrate 2 Mbps
Network
Wi-Fi Standard IEEE802.11b, 802.11g, 802.11n
Frequency Range 2.4 GHz ~ 2.4835 GHz
Channel Bandwidth Supports 20 MHz
Security 64 / 128-bit WEP, WPA / WPA2, WPA-PSK / WPA2-PSK
Transmission Rate 11b: 11Mbps, 11g : 54Mbps, 11n: 72Mbps
Wi-Fi Pairing AP pairing
Protocol EZVIZ cloud proprietary protocol
Interface Protocol EZVIZ cloud proprietary protocol
Wired Network RJ45 1 (10 M / 100 M Adaptive Ethernet Port)
Storage
Local Storage MicroSD card slot (Max. 256G)
Cloud Storage EZVIZ Cloud Storage
Function
Smart Alarm AI Person Detection
Customized Alert Area Supports
Audio Supports mic
General Function Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark
General
Operating Conditions -30C ~ 60C (14F to 113 F), Humidity 95% or less (non-condensing)
IP Grade IP65
Power Supply DC 12V / 1A
Power Consumption MAX. 6W
Dimensions 158 x 157 x 149 mm (6.22 x 6.18 x 5.87 inch)
Packaging Dimensions 197 x 185 x 205 mm (7.76 x 7.28 x 8.07 inch)
Weight 885 g (31.22 oz)
Net Weight 510 g (17.99 oz)
What's in the box
C8C Camera
1.5-Meter Power Adapter
Screw Kit
Waterproof Kit
Drill Template
Regulatory Information
Quick Start Guide
